Page 33
9.3.6 BACKLIT TIMER
This menu selection is used to setup the illumination time of the display and keypad.
1. Press and hold the [MENU/SET] key.
2.
Press the [▲] or [▼] key to select “CONFIG”, then press the [SELECT] soft
key.
3.
Select “BACKLIT TIMER” with the [▲] or [▼] key, then press the [SELECT] soft
key.
4.
Press the [▲] or [▼] key to select the desired
time.
OFF: Disables the display/key-
pad lamp illumination.
3/5/10/30 Sec: Illuminates the display/keypad for the selected time
when any key (except the PTT switch) is pressed.
CONTINUOUS: Illuminates the display/keypad continuously.
5. Press the [ENTER] soft key to store the selected level.
6. Press the [CLR/
] key to return to radio operation.
9.3.7 CONTRAST
The contrast may be adjusted in 30 levels.
1. Press and hold the [MENU/SET] key.
2.
Press the [▲] or [▼] key to select “CONFIG”, then press the [SELECT] soft
key.
3.
Select “CONTRAST” with the [▲] or [▼] key, then press the [SELECT] soft
key.
4. Press the [▲] or [▼] key to select the de-
sired level. The contrast level can be set
from “1” to “30” (“15” is default).
5. Press the [ENTER] soft key to store the se-
lected level.
6. Press the [CLR/ ] key to return to radio operation.
9.3.8 RESET
The memories and settings of each setup category may be initialized inde-
pendently, or the transceiver may be reset to the original factory settings.
1. Press and hold the [MENU/SET] key.
2.
Press the [▲] or [▼] key to select “CONFIG”, then press the [SELECT] soft
key.
3. Select “RESET” with the [▲] or [▼] key, then press the [SELECT] soft
key.
