GPS Chart 160/170C Page 29
4.1.5 Selecting the Language
It is possible to select the Language in which you wish information to be displayed (for
screen labels, menus and options, but it does not affect the map information). The
default setting is English.
'MENU' + "GENERAL SETUP" + 'ENTER' + "LANGUAGE" + 'ENTER'
Choose the Language you want and press 'ENTER' to confirm.
4.1.6 Setting the NMEA Sentences
4.1.6.1 Internal GPS Setup
It is possible to set the desired configuration for the Internal GPS.
'MENU' + "ADVANCED SETUP" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"INTERNAL GPS SETUP" + 'ENTER'
On the screen a menu is shown with the following options
, , .
Restart GPS
Restarts all GPS processes.
Static Navigation
Sets up a threshold for the
speed. When the speed received from the positioning
device is under that threshold, the chartplotter displays zero. The default value
is On.
Differential Correction Source
Allows the selection of the
Differential Correction Source signal among None, WAAS
and External RTCM. If the "NMEA2/RTCM INPUT" is set to NMEA the option External
RTCM cannot be selected. The chartplotter shows a Warning message. The default
setting is WAAS.
4.1.6.2 Autopilot Output
To connect the chartplotter to an Autopilot, select the desired sentences.
'MENU' + "ADVANCED SETUP" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"AUTOPILOT OUTPUT" + 'ENTER'
4.1.6.3 NMEA1 Output & NMEA2 Output
Allows selecting the set of NMEA-0183 sentences transmitted by the chartplotter.
For NMEA1:
'MENU' + "ADVANCED SETUP" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"NMEA1 OUTPUT" + 'ENTER'
For NMEA2:
'MENU' + "ADVANCED SETUP" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"NMEA2 OUTPUT" + 'ENTER'
