Page 30 GPS Chart 160/170C
Figure 4.1.6.3 - NMEA Sentences
4.1.6.4 NMEA2/RTCM Input
Selects the input type among NMEA and RTCM 1200, 2400, 4800, 9600, 19200,
38400 (where the number means the Baud Rate of the RTCM signal). By selecting
RTCM the Differential Correction Source is automatically set to External RTCM. If
NMEA2/RTCM Input is different from NMEA or RTCM 4800, the NMEA2 Output is
stopped and a warning message will be shown. The default setting is NMEA.
'MENU' + "ADVANCED SETUP" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"NMEA2/RTCM INPUT" + 'ENTER'
4.1.6.5 Send/Rec RTE&MARKS Port
Allows selection from which port the NMEA RTE and WPL sentences are sent/
received (to transfer Marks or Routes).
'MENU' + "ADVANCED SETUP" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"SEND/REC RTE&MARKS PORT" + 'ENTER'
4.1.7 Additional C-CARDs
The chartplotter uses two types of C-MAP optional cartridges: either a chart cartridge
or a data storage cartridge. A chart cartridge, called C-CARD, contains detailed charts
of the area covered. A data storage cartridge, called User C-CARD can be used to
permanently store your Waypoints, Marks and tracks.
4.1.7.1 Inserting C-CARD
Hold the C-CARD by the long inclined side so that you can see the C-MAP label.
Figure 4.1.7.1 - Inserting/Removing C-CARD (I)
