Operation Guide 25

Stanford Research Systems DC215 Voltage/Current Source

If the present value is within the limits of the new range, the output is set to that value.

If the present value is not valid for the new range, the output is set to 0, and the output

remains on.

Changing ranges terminates any existing ramp, jumping to the final value of the ramp,

resetting the ramp timer terminating any R

delay

and pulsing Ready.

TABLE 1: VOLTAGE RANGES

Range

Source Range

Resolution

Max Current

1 V

±1.20000 V

10 μV

±240 mA

10 V

±12.0000 V

100 μV

±240 mA

30 V

±32.000 V

1 mV

±240 mA

TABLE 2: MV RANGES

Range

Source Range

Resolution

Max Current

10 mV

±12.0000 mV

100 nV

~±66.7 mA

100 mV

±120.000 mV

1 μV

~±6.06 mA

* A voltage divider is used for the 10 & 100 mV ranges, with an output impedance of

~2.0 Ω. When used into low resistance loads, the output voltage may decrease.

TABLE 3: CURRENT RANGES

Range

Source Range

Resolution

Max Current

1 mA

±1.20000 mA

10 nA

±32 V

10 mA

±12.0000 mA

100 nA

±32 V

100 mA

±120.000 mA

1 μA

±32 V

200 mA

±240.000 mA

10 μA

±32 V

Value

The Source Value display is in the Settings list, accessed by the Setting [↑] and [↓]

keys.

Source value can be set anywhere within the selected range using:

▪ Numeric keys

▪ Cursor keys

▪ <SORC> command

Values outside of the selected range will be rejected and an error message will be

displayed.

Ramping

The DC215 can be set to linearly ramp between output values.

If the Ramp Time (T

ramp

) is set to zero, the output immediately jumps to the next source

value. If the Ramp Time is set to a non-zero value, the output will ramp from the

Previous Source Value to the New Source Value in T

ramp

seconds.

123456789101112131415161718192021222324252627282930313233343536373839404142434445464748495051525354555657585960616263646566676869707172737475767778798081828384858687888990919293949596979899100101102103104105106107108109110111112113114115116117118119120121122123124125126127128129130131132133134135136137138139140141142143144145146147148149150151152153154155156157158159160161162163164165166167168169170171172173174175176177178179180181182183184185186187188189190191192193194195196/ 196
