Operation Guide 26

Stanford Research Systems DC215 Voltage/Current Source

The slope of the ramp is:

𝑁𝑒𝑤 𝑆𝑜𝑢𝑟𝑐𝑒 𝑉𝑎𝑙𝑢𝑒 − 𝑃𝑟𝑒𝑣𝑖𝑜𝑢𝑠 𝑆𝑜𝑢𝑟𝑐𝑒 𝑉𝑎𝑙𝑢𝑒

𝑅𝑎𝑚𝑝 𝑇𝑖𝑚𝑒

Ramps behave slightly differently for the Sequence mode. See Ramps and Sequences

(page 45) for details on ramping behavior in the Sequence mode.

Ramp Time (T

ramp

)

T

ramp

(ramp time) is in the Setting list, accessed by the Setting [↑] and [↓] keys.

T

ramp

can be set between 0.0 and 3600.0 s in 0.1 s increments, using the following:

▪ Numeric keys

▪ Cursor keys

▪ <RTIM> command

Values outside of 0.0 and 3600.0 s will be rejected and an error message will be

displayed.

Behavior during ramping

▪ The Real Time Display (in the Setting list) shows the instantaneous value being

output during a ramp. See Real Time Display (page 28) for details on its

behavior.

▪ If the output is turned ON with ramping active, the output ramps from “0” to

the set value using the ramp timing.

▪ If the output is turned off with ramping active, the output turns off

immediately (no ramp).

▪ If the Source Type is changed during a ramp, the output turns off immediately

(no ramp) and normal Source Type change behavior applies.

▪ If the range or BW is changed during a ramp, the output immediately jumps to

final value of the ramp, and normal range change behavior applies.

▪ If the Source Value or Ramp Time are changed during a ramp, the previous

ramp is considered to have ended and a new ramp is calculated from that point

and started. This ramp starts from the present output value & ends at the

(new) Source Value, using the (new) Ramp Time.

▪ Most functions act as usual, with a few special cases listed below.

When a ramp is active

▪ The output ramps at the calculated rate.

▪ The Source Display shows the final value.

▪ The Real Time display shows the present output value.

▪ The RAMP LED is lit.
