Basics 15

Stanford Research Systems DC215 Voltage/Current Source

Remote Interface Indicators

These indicate activity and status for the remote interface. See Remote Programming

(page 111) for details.

▪ Rem (Remote): Indicates that the DC215 is in Remote Mode.

▪ Act (Activity): Flashes while there is activity on one of the remote interfaces.

▪ Err (Error): Indicates that an error occurred on one of the remote interfaces.

USB Socket

The USB A-Type socket is used to connect an external USB drive (usually a memory

stick) to the DC215 to load or store sequences or to store logging files. It supports

USB2.0: high speed mass storage (MSC) class.

When communicating with the USB device, the USB indicator is illuminated. See USB

Memory Device Interface (page 67) for details.

Output and Sense Connections

The Source Output and Sense connectors on the front panel contain the output

terminals for the voltage and current source.

The red and black terminals on the left side under the OUTPUT label are the HI and LO

output terminals for both the voltage and current source types. See Output

Connections (page 22) for details.

The red and black terminals on the right side under the SENSE label are the HI and LO

voltage sense terminals when the 4-wire sense mode is selected. Note that in 4-wire

mode, the Sense terminals are connected to the corresponding Output terminals

through 1 MΩ resistors. The Sense terminals are not connected for the 2-wire sense

mode. See Remote Sensing (page 80) for details.

The Blue terminal to the right of the sense terminals is the GUARD connection, which

can connect to the internal guard shield. See Guarding (page 82) for details.
