Manual Conventions and Organization vii

Stanford Research Systems DC215 Voltage/Current Source

Example 6: Sequence

1) If a sequence has been previously saved in the DC215, perform a power-on

[CLR] to erase the sequencer memory. Otherwise just do [RCL] [0] to load the

default setup.

2) Connect the DC215 Output terminals (Hi and Lo) to the DMM voltage input

terminals (Hi and Lo) with banana cables. Set the DMM to DC voltage and

autorange.

Create Sequence

3) Press [PROG] to enter Program mode.

4) Press the following keys to enter a six point sequence:

[0] [V/A]

[1] [V/A]

[2] [V/A]

[3] [V/A]

[4] [V/A]

[5] [V/A]

5) Press [PROG] to exit the Program mode.

Configure Sequence Parameters

6) Press [SHIFT] [.] to enter Sequence menu. Press the [↓] cursor key to display

the time submenu, then [→] to enter it. Type [6] [Enter] to set the step time to

6 s.

7) Press the [↓] cursor key to display the repeat submenu, then [→] to enter it.

Press [↓] to toggle the repeat mode to “On’, then [Enter] to set.

8) Press the [↓] cursor key twice to the display submenu, then [→] to enter it.

Press [↓] to toggle to “MEAS’, then [Enter] to set.

9) Press the [←] cursor key to exit the sequence menu.

Configure Measurement

10) Press [SHIFT] [4] to enter the Measure menu. Press the [→] cursor key to enter

the trigger submenu. Press [↓] to display “timE”, then [Enter] to set.

11) Press the [↓] cursor key to display the measure time menu, then [→] to enter

it. Type [.] [5] [Enter] to set the measurement time to 0.5 s.

12) Press the [↓] cursor key to display the integration time menu, then [→] to

enter it. Press [↑] to display “mEd”, then [Enter] to set.

13) Press the [←] cursor key to exit the measurement menu.

14) Press [SHIFT] [2] to toggle the monitor display to voltage.
