Manual Conventions and Organization v
Stanford Research Systems DC215 Voltage/Current Source
Example 4: Measurements
This section describes how to configure measurements and ramping.
1) Press [Recall] [0] to recall the default setup.
2) Connect the DC215 Output terminals (Hi and Lo) to the DMM voltage input
terminals (Hi and Lo) with banana cables. Set the DMM to DC voltage and
autorange.
3) Turn the DC215 output on and set the source voltage to +0.10 V. The DMM
should read about +100.00 mV.
Configure Measurement
4) Press [SHIFT] [2] to toggle the monitor display to voltage. It should read about
+100.00 mV.
5) Press [SHIFT] [4] to enter the Measure menu and [→] to enter the trigger
submenu. Press [↓] to display “timE”, then [Enter] to set.
6) Press the [↓] cursor key to display the measure time menu, then [→] to enter
it. Type [.] [2] [Enter] to set the measurement time to 0.2 s. (Note that the
Mrate indicator is flashing).
7) Press the [↓] cursor key to display the integration time menu, then [→] to
enter it. Press the [↓] cursor key twice to display “FASt”, then [Enter] to set.
(Note that the Mrate indicator has stopped flashing).
8) Press the [←] cursor key to exit the measurement menu.
Examine Voltage Monitor
9) Note that the monitor measurements are updating more rapidly.
10) Turn the output off.
