Je bekijkt pagina 26 van 196
Manual Conventions and Organization iv
Stanford Research Systems DC215 Voltage/Current Source
Example 3: Setting Current and Voltage Limits
This section describes how to set the current and voltage limits.
1) Press [Shift] [7] to enter the recall menu. Press [0] [Enter] to recall the default
setup.
Current Limits
2) Connect the DC215 Output terminals (Hi and Lo) to the 1 kΩ load resistor using
the banana to clip leads.
3) Turn the DC215 output on and set the source voltage to 10 V. The DC215
current monitor should read about +10.0 mA.
4) Press the [↓] SETTING key two times until +Lim is displayed. Type [5] [mV/mA]
to set the +Limit to +5 mA.
5) The +Lim indicator (top right side of front panel) should light and the DC215
current monitor should read about 5.00 mA.
Voltage Limits
6) Turn the DC215 output off. Change the source type to current.
7) Press the [↑] SETTING key twice until Source is displayed.
8) Turn the DC215 output on and set the source current to -10 mA. The DC215
voltage monitor should read about -10.0 V.
9) Press the [↓] SETTING key three times until -Lim is displayed. Type [-] [5] [V/A]
to set the -limit to -5 V.
10) The -Lim indicator (top right side of front panel) should light and the DC215
voltage monitor should read about -5.00 V.
11) Turn the output off.
