for multiple pulses, each pulse will deduct from the vend price
value set up in Start Pulse Value until the vend is satisfied.
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2.
Press the DELICATE (∧) or the HOT (∨) keypad until Prog
appears in the display. Press the START (enter) keypad, and
AtS 1 will appear in the display.
3. Press the DELICATE (∧) or the HOT (∨) keypad to scroll
through the programmable options until PLSNod appears in
the display.
4. Press the DELICATE (∧) or the HOT (∨) keypad to scroll
through the programmable options until PULSE appears in the
display. Press the START (enter) keypad, and PLSdEn will
appear in the display.
5. Press the DELICATE (˄) or the HOT (˅) keypad to scroll
through the programmable options until PLSNod appears in
the display, press the START (enter) keypad. oFF SingLE
or NULt a will appear in the display. This number corre-
sponds to the current Start Pulse Mode Programming Value.
6. Locate the desired value in the first column of Table 2 .
PLSNod
Start Pulse Mode Value Single Pulse/Multiple
Pulses
SingLE
Single Pulse
NULt
Multiple Pulses
* Factory default setting.
Table 2
7. Press the DELICATE (∧) or the HOT (∨) keypad to cycle be-
tween the options until correct.
NOTE: To go back to the current programmable op-
tion without changing the current value, press the
WARM (<) keypad.
8. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
Programmable Output Type AtyPE
This option allows the owner to program when the control pro-
vides an output that can be used for variety of reasons.
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2.
Press the DELICATE (∧) or the HOT (∨) keypad until Prog
appears in the display. Press the START (enter) keypad, and
AtS 1 will appear in the display.
3. Press the DELICATE (∧) or the HOT (∨) keypad to scroll
through the programmable options until AtyPE appears in the
display.
4.
When AtyPE appears in the display, press the START (enter)
keypad. A number will appear in the display. This number
corresponds to the current Output Type Value.
5. Press the DELICATE (∧) or the HOT (∨) keypad to increase
or decrease the current number to the desired number selected
from Table 3 .
Programmable Out-
put Type Value
Mode(s) in Which
Available Signal is
Active
0* - Available Ready Mode only
1 - Available with Start Ready Mode, Start Mode
2 - Available with End of
Cycle
Ready Mode, End of Cy-
cle Mode
3 - Available with Start
and End of Cycle
Ready Mode, End of Cy-
cle Mode, Start Mode
4 - Vend is Not Satisfied Ready Mode, Partial
Vend Mode
5 - Vend is Not Satisfied
with End of Cycle
Ready Mode, Partial
Vend Mode, End of Cycle
Mode
6 - Available with Vend Ready Mode, Partial
Vend Mode, Start Mode
7 - Available with Vend
and End of Cycle
Ready Mode, End of Cy-
cle Mode, Partial Vend
Mode, Start Mode
8 - Machine is In Use Door Locking, Door/Lid
Unlocking, Overflow
Mode, Pause Mode, Run
Mode
9 - Cycle is Complete End of Cycle
10 - Lucky Cycle For 10 seconds when
Start Mode is entered
11 - Break in Alarm For 15 seconds when
Break in Alarm is trig-
gered at same time as au-
dio output tone
12 - End of Cycle is En-
tered
For 3 seconds when End
of Cycle Mode is entered
Table 3 continues...
