Programmable Out-
put Type Value
Mode(s) in Which
Available Signal is
Active
13 - Motor Running Whenever Motor is run-
ning
14 - Machine Error Present Machine Error Mode
*Factory default setting.
Table 3
6. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
Default Cycle dFtCyC
This option allows the owner to set the default cycle that the ma-
chine will enter when in the Ready Mode.
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2.
Press the DELICATE (∧) or the HOT (∨) keypad until Prog
appears in the display. Press the START (enter) keypad, and
AtS 1 will appear in the display.
3. Press the DELICATE (∧) or the HOT (∨) keypad to scroll
through the programmable options until dFtCyC appears in
the display.
4.
When dFtCyC appears in the display, press the START (en-
ter) keypad. A number will appear in the display. Refer to ta-
ble below. This number corresponds to the current default cy-
cle value. The corresponding LEDs will also be lit.
Cycle Number on Display
NORMAL / HOT 1
NORMAL / WARM 2
NORMAL / COLD 3
SYNTHETIC / HOT 4
SYNTHETIC / WARM 5
SYNTHETIC / COLD 6
DELICATE / HOT 7
DELICATE / WARM 8
DELICATE / COLD 9
Table 4
5. Press the DELICATE (∧) or the HOT (∨) keypad to increase
or decrease the current number to the desired number.
6. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
Audio Signal AUdio
This option allows the owner to program when the signal will
sound.
There are five occasions when a signal may sound during the
washer operation. These five occasions are listed below:
1. End of Cycle Signal By default, the signal is turned off. If
turned on, the signal will sound for three seconds at the end of
a cycle.
2. Keypad Depression Signal By default, this signal is turned
on and will sound for a quarter of a second. This signal will
sound each time a keypad is pressed.
3. Coin Input/Card Insertion Signal By default, this signal is
turned on and will sound for a quarter of a second each time a
coin or card is entered.
4. Remove Card Signal (Card Models Only) By default, this
signal is turned on and will sound one second on and one sec-
ond off when the control is prompting for card removal.
5. Signal for Start By default, this signal is turned on and will
sound one second on and one second off for 10 seconds after
vend price has been satisfied.
How to Program the Audio Signal
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2.
Press the DELICATE (∧) or the HOT (∨) keypad until Prog
appears in the display. Press the START (enter) keypad, and
AtS 1 will appear in the display.
3. Press the DELICATE (∧) or the HOT (∨) keypad to scroll
through the programmable options until AUdio appears in the
display.
4.
When AUdio appears in the display press the START (enter)
keypad. A number will appear in the display. This number
corresponds to the current Audio Signal Programming Value.
5. Locate the desired number in the first column of Table 5 on
the following page.
6. Press the DELICATE (∧) or the HOT (∨) keypad to increase
or decrease the current number until correct.
For Example: A user might wish to have the signal sound only
when a keypad is pressed. Entering the number “1” in step 5
would turn off all the options except KEYPAD. In this instance,
the signal would sound only when a keypad is pressed.
7. Press the START (enter) keypad when the correct number ap-
pears in the display. The next option will appear in the dis-
play.
How to Read Audio Signal Table
To determine the correct number required to program the Audio
Signal, use the following chart. The Signal Value column con-
Programming Control
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
52 Part No. 807870ENR4
