Je bekijkt pagina 112 van 119
Error Codes
Display Description Cause/Corrective Action
E LF
Water Leak Fill
Error
If the water level has raised more than an acceptable amount in a during a water leak
check, the control will save a water leak error status and will continue the machine
cycle. Immediately upon detecting the error the right-most decimal point will be lit.
This lit decimal point can be cleared by pressing the START keypad 3 times in a peri-
od of 5 seconds or by cycling the power to the machine.
Display is dim Look for loose pins and damaged wires on harness from user control to drive board.
E d
Drive Board Errors
E d 10
Voltage Select Er-
ror
Wrong Input Voltage seen at drive board 120V vs 240V. Water may be on drive board.
Let drive dry out and determine cause of water. Unpower to clear error. Replace drive
board if error persists.
E d 12
Over Voltage AC-
Main Input Error
Machine voltage is too high, check supply voltage to the machine and verify that it is
within machine specifications. Unpower to clear error. Replace drive board if error
persists.
E d 13
Power Fail Dan-
gerous Error
The Neutral Line power input to the machine was seen out of range. Unpower to clear
error. Check for damage in the power supply harness. Replace power supply harness
or drive board if error persists.
E d 21
Over Voltage DC
Bus Error
Unpower to clear error. Check voltage input to machine. If it happens only at start of
spin, replace motor. Replace drive board if error persists.
E d 22
Over Motor Tem-
perature Error
Motor temperature is detected to be too high. Check that drum spins freely when emp-
ty. Check for overloading of machine. Check motor harness for damage. Reduce agita-
tion time and duty cycle ifrotate/pause times are very short and programmable. Un-
power to clear error. Replace drive board if error persists.
E d 23
Fatal IPM Over
Current Shunt Er-
ror
Check that drum and motor spins freely. Unpower to clear error. Check the motor
phase windings. Continuity should be uniform between phases L1 and L2, L2 and L3,
L1 and L3. Replace motor if not uniform. Replace drive board if error persists.
E d 24
Fatal I2T Hard-
ware Over Current
Error
Check that drum and motor spins freely. Rotor may be locked up. Check the motor
phase windings. Continuity should be uniform between phases L1 and L2, L2 and L3,
L1 and L3. Replace motor if not uniform. Unpower to clear error. Replace drive board
if error persists.
E d 25
IPM Over Temper-
ature Error
IPM temperature is detected to be too high. Check that drum spins freely when empty,
check for overloading of machine, reduce agitation time, and duty cycle if rotate/pause
times are very short and programmable. Unpower to clear error. Check for lint build-
up on heat sink on drive board. Replace drive board if error persists.
E d 29
Motor Not Con-
nected Error
The motor or one of its electrical phases is not connected. Check that the harness from
the motor to the drive board is fully plugged in on both ends and that there is no dam-
age to the motor harness. Make sure to push in the motor harness on both ends just in
case it is a little loose and not fully inserted. If the harness looks fine and the error still
occurs, try replacing the drive board or harness. Unpower to clear error.
Table continues...
Error Codes
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
112 Part No. 807870ENR4
