Remove Shipping Materials
1. Remove two screws at bottom of front access panel. Rotate
bottom of panel out and remove panel.
FLW2451N_SVG
Figure 3
2. Remove two 9/16 inch bolts and washers holding shipping
brace to weight.
3. Remove two 9/16 inch bolts and washers holding shipping
brace to washer base and remove brace.
FLW2452N_SVG
Figure 4
4. Go to rear of washer and pull label from rear shipping bolts.
5. Remove two 9/16 inch bolts. Unscrew each bolt while apply-
ing forward pressure just until bolt stops unthreading. Work
each bolt and spacer out by hand using a circular motion.
NOTE: Avoid backing bolts out completely or
spacers might fall into cabinet.
Figure 5
6. Insert two plugs included in accessories bag into rear ship-
ping bolt holes.
FLW2358N_SVG
Figure 6
7. Replace front access panel.
8. Save all shipping materials. They must be reinstalled any
time washer is moved more than four feet.
IMPORTANT: Do not lift or transport unit from
front or without shipping materials installed. Refer
to the User’s Guide for proper instructions on re-
installing the shipping materials.
Connect Fill Hoses
WARNING
Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period and before using the
washer, turn on all hot water faucets and let the
water flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas is
flammable. Do not smoke or use an open flame
during this time.
W029
NOTE: If installing an accompanying steam dryer, a
Y-Connector may be needed. Check dryer installation
manual to confirm.
Installation
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. 806987ENR3
