Do not connect the INPUT and OUTPUT
connectors to a hub. The input/output signals for
these connectors are unique to the product and
are not Ethernet signals. In particular, be aware
that connecting these connectors to a PoE
injector hub may result in damage to the
product.
Optical Receiver ZRA-R1
Front
POWER indicator
Indicates the power status of the product.
Off: Power is turned off.
Blinking red: Power error occurred.
Lit green: Power is turned on (normal
o
perating status).
IN
PUT indicator
Indicates the status of the SFP+ input
c
onnector.
Off: The SFP+ input connector is not
c
onnected or not linked with ZRA-T1.
Lit green: The SFP+ input connector works
pr
operly.
Blinking red: An error occurred on the SFP+
inp
ut connector.
OUT
PUT indicator
Indicates the status of RJ45 output
c
onnectors 1 to 3.
Lights up regardless of whether it is
c
onnected to the Display Cabinet or not.
Off: The RJ45 output connectors are not
outp
utting images.
Lit green: RJ45 output connectors work
pr
operly.
Blinking red: An error occurred on RJ45
ou
tput connectors*.
* If the indicator is blinking every
0
.25 seconds, turn off the power and on
again. If it is still not improved, contact your
local Sony representative.
The INPUT indicator and OUTPUT indicator blink
in
red for about 5 seconds shortly after turning
the power on or connecting cables. If blinking in
red continues for over 30 seconds, turn off the
power and on again or check the cable
connection. If it still does not improve, contact
your local Sony representative.
Rear
DC power input connector (USB Type-C)
Use a USB Type-C - Type-C cable (not
s
upplied) to connect this connector to the
USB Type-C output on the USB AC adapter
(not supplied).
For the USB AC adapter, use a product with a
US
B Type-C with an output voltage of 5 V or
higher and an output current 2 A or higher.
For the USB Type-C - Type-C cable, use a
p
roduct with a current 2 A or higher.
OUTP
UT connectors 1 to 3 (RJ45)
Use a Category 7 cable (not supplied) to
c
onnect this connector to the IN (cabinet
input) connector on the Display Cabinet.
The connectors 1 to 3 correspond to the
I
NPUT connectors 1 to 3 of ZRA-T1
respectively.
Up to 3 cables can be connected to these
c
onnectors. Connect to connector 1 when you
connect 1 cable, connector 1 and 2 when you
connect 2 cables, and all connectors when
you connect 3 cables.
INPUT connector (SFP+)
Use an SFP+ transceiver module (not
s
upplied) and optical fiber cable (not
Note
Note
