Parts Identification
Optical Transmitter ZRA-T1
Front
POWER indicator
Indicates the power status of the product.
Off: Power is turned off.
Blinking red: Power error occurred.
Lit green: Power is turned on (normal
o
perating status).
IN
PUT indicator
Indicates the status of RJ45 input connectors
1 to
3.
Off: RJ45 input connectors are not connected
or
not linked with the Display Controller.
Lit green: RJ45 input connectors work
pr
operly.
Blinking red: An error o
ccurred on RJ45 input
connectors*.
* If the indicator is blinking every
0
.25 seconds, turn off the power and on
again. If it is still not improved, contact your
local Sony representative.
OUT
PUT indicator
Indicates the status of the SFP+ output
c
onnector.
Off: The SFP+ output connector is not
c
onnected or not linked with ZRA-R1.
Lit green: The SFP+ output connector works
pr
operly.
Blinking red: An error occurred on the SFP+
ou
tput connector.
The INPUT indicator and OUTPUT indicator blink
in r
ed for about 5 seconds shortly after turning
the power on or connecting cables. If blinking in
red continues for over 30 seconds, turn off the
power and on again or check the cable
connection. If it still does not improve, contact
your local Sony representative.
Rear
DC power input connector (USB Type-C)
Use a USB Type-C - Type-C cable (not
s
upplied) to connect this connector to the
USB Type-C output on the USB AC adapter
(not supplied).
For the USB AC adapter, use a product with a
US
B Type-C with an output voltage of 5 V or
higher and an output current 2 A or higher.
For the USB Type-C - Type-C cable, use a
p
roduct with a current 2 A or higher.
I
NPUT connectors 1 to 3 (RJ45)
Use a Category 7 cable (not supplied) to
c
onnect this connector to the OUTPUT
connector on the Display Controller.
The connectors 1 to 3 correspond to the
O
UTPUT connectors 1 to 3 of ZRA-R1
respectively.
Up to 3 cables can be connected to these
c
onnectors. Connect to connector 1 when you
connect 1 cable, connector 1 and 2 when you
connect 2 cables, and all connectors when
you connect 3 cables.
OUTPUT connector (SFP+)
Use an SFP+ transceiver module (not
s
upplied) and optical fiber cable (not
supplied) to connect this connector to the
INPUT connector on ZRA-R1.
This product is authenticated with safety
st
andards for use in combination with the
SFP+ transceiver module.
Contact your local Sony representative for
o
ther SFP+ transceiver modules.
• OTM-10GSR1 (Sony Corporation)
Note
