7
supplied) to connect this connector to the
OUTPUT connector on ZRA-T1.
This product is authenticated with safety
st
andards for use in combination with the
SFP+ transceiver module.
Contact your local Sony representative for
o
ther SFP+ transceiver modules.
• OTM-10GSR1 (Sony Corporation)
Do not connect the INPUT and OUTPUT
c
onnectors to a hub. The input/output signals for
these connectors are unique to the product and
are not Ethernet signals. In particular, be aware
that connecting these connectors to a PoE
injector hub may result in damage to the
product.
Usage of this product
1 Connect the RJ45 cable.
ZRA-T1:
Connect the Display Controller and ZRA-T1
with
a Category 7 cable. (Cable length: within
3 m)
• OUTPUT connectors 1 to 6 and OUTPUT
c
onnectors 7 to 12 on the Display Controller
cannot be mixed when connecting.
• OUTPUT connectors 1 to 12 on the multiple
D
isplay Controllers cannot be mixed when
connecting.
ZRA-R1:
Connect the Display Cabinet and ZRA-R1 with
a Cat
egory 7 cable. (Cable length: within
10 m)
2 Connect the SFP+/OM3 cable.
Attach the SFP+ transceiver module to the
SF
P+ output connector on ZRA-T1 and the
SFP+ input connector on ZRA-R1.
Connect SFP+ transceiver modules to each
ot
her with the optical fiber cable.
3 Connect the USB cable.
Connect the USB AC adapter to ZRA-T1/ZRA-
R
1 with the USB Type-C - Type-C cable.
• Do not use the USB Type-A - Type-C cable.
It
may cause a malfunction.
• If the USB AC adapter or USB Type-C cable
ha
s malfunctioned, this unit may not power
on.
The power turns on after connecting the
c
able and the POWER indicator lights green.
If the POWER indicator blinks red, remove the
US
B Type-C cable from the product.
4 Remove the USB cable.
Remove the USB Type-C - Type-C cable from
ZR
A-T1/ZRA-R1.
The POWER indicator turns off and the power
turns off
.
Note
Notes
Notes
