Adjustment Using the Menus
87
3D SIGNAL
FORMAT
Selects input signal format for 3D
display.
• 3G-B: Displays 3G Level-B HD-SDI
signals for 3D display mode.
•INTER: Displays 1080/50i or
1080/60i signal.
•PROG: Displays 1080/24P, 25P,
30P or 720/50P, 60P signal.
•PSF: Displays 1080/24PsF or
1080/25PsF signal.
• DUAL: Displays dual-stream HD-SDI
signals for 3D display mode.
•INTER: Displays 1080/50i or
1080/60i signal.
•PROG: Displays 1080/24P, 25P,
30P or 720/50P, 60P signal.
•PSF: Displays 1080/24PsF or
1080/25PsF signal.
• SEQUENTIAL: Displays field
sequential HD-SDI signals for 3D
display mode.
• SIDE BY SIDE 1: Displays side-by-
side typed HD-SDI signals for 3D
display mode.
•INTER: Displays 1080/50i or
1080/60i signal.
•PROG: Displays 1080/24P, 25P,
30P or 720/50P, 60P signal.
•PSF: Displays 1080/24PsF or
1080/25PsF signal.
• SIDE BY SIDE 2: Displays non-
compressed horizontal resolution
side-by-side typed HD-SDI
signals for 3D display mode.
•INTER: Displays 1080/50i or
1080/60i signal.
•PROG: Displays 1080/24P, 25P,
30P or 720/50P, 60P signal.
•PSF: Displays 1080/24PsF or
1080/25PsF signal.
• LINE BY LINE: Displays line-by-
line typed HD-SDI signals for 3D
display mode.
DISPARITY SIM. Adjusts the phase of left/right input
signals. You can monitor the depth of 3D
images using simulated 3D effect.
• LR: Shifts the phase of left and right
channels at the same time.
• LEFT: Shifts the phase of left
channel.
• RIGHT: Shifts the phase of right
channel.
Submenu Setting
HOROPTER
CHECK
Select ON to switch the display settings
for the left/right channel signals. Select
OFF when you do not wish to perform
switching. By changing the display
settings, the left/right signals become
easier to identify.
• NORMAL: Displays video signals.
• BLACK: Displays black signals. (No
video signals)
• MONO: Displays video signals as
grayscale image.
• RED: Displays video signals as RGB
red color component.
• BLUE: Displays video signals as RGB
blue color component.
FLIP H Changes display patterns (normal/
horizontally reversed display) in
monitoring left/right input signals.
• OFF: Deactivates the reversing
function.
• LEFT: Horizontally reverses left
signal.
• RIGHT: Horizontally reverses right
signal.
720P SCAN Selects scan mode for 720P input
signals.
• NORMAL: Displays normal scan.
• NATIVE: Displays native scan.
GRID Selects ON to display a grid for checking
the overall image disparity, and OFF not
to display grid.
• H GRID WIDTH: Enables to change
the grid width (horizontal). You
can select from 0.50% to 10.00%.
• V GRID HEIGHT: Enables to change
the grid height (vertical). You can
select from among OFF, 16.7%,
12.5%, 10% and 8.3%.
DISPARITY
RULER
Selects ON to display two vertical lines
for measuring the disparity, and OFF not
to display.
• RULER POSITION: Enables to
move the two lines as a pair to the
desired position for measuring
the disparity.
• DISPARITY: Enables to move only
one of the two lines to measure
the disparity.
GRID/RULER
INTENSITY
Enables to adjust display brightness of
the lines for GRID and DISPARITY
RULER functions.
AUTO L/R SW Selects ON to automatically switch the
left and right of 3D input signals, and
OFF not to switch.
• SWITCHING INTERVAL: Selects
the interval from among SHORT,
MEDIUM and LONG.
Submenu Setting
