Adjustment Using the Menus
88
REMOTE menu
3G-B DEFAULT
CH
Sets the signal to be displayed (left or
right) when 3G-B signal is input and 2D
is selected for the display mode.
• LEFT: Displays the 3G-B left channel
signal.
• RIGHT: Displays the 3G-B right
channel signal.
DIFFERENCE The difference between the luminance
signal component of the left signal (L)
and that of the right signal (R) is
displayed.
A gray portion indicates that the
luminance level of the two signals is the
same. When the luminance level of the
two signals is not the same, a
monochrome image is displayed
according to the difference in the
luminance. This function is useful for
checking the disparity level.
VIRTUAL SUB.
MAR.
Displays two squares as a pseudo-3D
subject marker to check the disparity for
3D display.
The 3D SETTING 3/3 menu screen
becomes semi-transparent.
• H SIZE: Enables adjustment of the
marker width.
• V SIZE: Enables adjustment of the
marker height.
• H POSITION: Enables horizontal
movement of the marker.
• V POSITION: Enables vertical
movement of the maker.
• DISPARITY: Enables change to the
disparity of the marker.
Submenu Setting
PARALLEL REMOTE:
SERIAL REMOTE: xxxxxxx
MONITOR:
CONTROLLER:
CONNECTION: xxx
REMOTE
Submenu Setting
PARALLEL REMOTE Selects the PARALLEL REMOTE
connector pins for which you want
to change the function.
You can assign various functions to
1 to 4 pins and 6 to 8 pins. The
following lists the functions you
can assign to the pins.
• – – – (“– – –”: No function is
assigned.)
•COMPOSITE
•Y/C
•RGB
• COMPONENT
•DVI
• HD15
• OPTION A-1
• OPTION A-2
• OPTION B-1
• OPTION B-2
• OVERSCAN
• FULL (LMD-2451TD)
• NORMAL
•NATIVE
•4:3
•16:9
• TALLY R (LMD-2451TD)
• TALLY G (LMD-2451TD)
• EXT SYNC
• BLUE ONLY
• MONO
• H/V DELAY
• 16:9 MARKER
• 15:9 MARKER
• 14:9 MARKER
• 13:9 MARKER
•1.85:1 MARKER
•2.35:1 MARKER
• 1.85:1 & 4:3 MARKER
•4:3 MARKER
• CENTER MARKER
• SAFE AREA 80%
• SAFE AREA 85%
• SAFE AREA 88%
• SAFE AREA 90%
• SAFE AREA 93%
• MARKER MAT HALF
• MARKER MAT BLACK
• 2D/3D SELECT
• CHECKERBOARD
•L/R SWITCH
• HOROPTER CHECK
•DISPARITY SIM.
•GRID
• AUTO L/R SW
• 3G-B DEFAULT CH
• VIRTUAL SUB. MAR.
• DISPARITY RULER
• DIFFERENCE
•720P SCAN
• MENU –
• MENU +
