Adjustment Using the Menus
83
Items” on page 64 and “3D Input Signals and
Adjustable/Setting Items” on page 65.
SCAN
Press the button to change the scan size of the picture
according to the setting of STANDARD or
FULL+NATIVE selected in SCAN (page 79).
ASPECT
Press the button to set the aspect ratio of the picture, 4:3
or 16:9.
Note
The panel of LMD-2451TD has 16:10 aspect ratio.
When the 16:9 signal is displayed, black bars appear in
the upper and lower positions of the display. This is not
a malfunction. (See “Scan mode image” on page 80.)
EXT SYNC (external sync)
Press the button to operate the unit on an external sync
signal through the EXT SYNC IN connector.
EXT SYNC works when the component/RGB signals
are input.
I/P MODE
Press the button to set the delay by the picture
processing to the minimum level when interlace signal
is input. The mode switches in the sequence INTER-
FIELD t FIELD MERGE t LINE DOUBLER with
every press of the button (see page 80).
MULTI DISPLAY
Press the button to display the multi display. Set the
multi display setting in the MULTI DISPLAY
SETTING menu (see page 81).
CLOSED CAPTION
Press the button to display the closed caption. Set the
closed caption setting in the CLOSED CAPTION
SETTING menu (see page 84).
Not available for the signal input from BKM-227W.
MONO
Press the button to display a monochrome picture. When
the buttons is pressed again, the monitor switches
automatically to color mode.
H/V DELAY
Press the button to observe the horizontal and vertical
sync signals at the same time.
MARKER
Press the button to display the marker. Set the aspect
marker and safety area size in the MARKER SETTING
menu (see page 81).
APA (Auto Pixel Alignment)
Press the button to adjust the picture automatically to
maximum clarity for the signal input to the HD15 input
connector. For finer according to the input signal, see
DOT PHASE on page 79.
When the menu screen is displayed, the APA does not
function.
Note
If the APA operation does not finish correctly depending
on the input signal, adjust DOT PHASE (page 79).
BLUE ONLY
Press the button to eliminate the red and green signals.
Only blue signal is displayed as an apparent
monochrome picture on the screen. This facilitates
chroma and phase adjustments and observation of signal
noise.
2D/3D SELECT
Press the button to switch from 2D display mode to 3D
display mode. Pressing the button again switches to 2D
display mode. You can change the 3D display settings
using the 3D SETTING menu.
CHECKERBOARD
Press the button to display the left/right 3D input signals
in a checkerboard pattern on the screen, allowing you to
simultaneously monitor the two signals. Pressing the
button again displays the input signals in default pattern.
L/R SWITCH
Press the button to quickly switch the left/right 3D input
signals, allowing you to easily compare each signal.
HOROPTER CHECK
Press the button to select display formats in monitoring
left/right signals for 3D image display. Select the desired
format from HOROPTER CHECK (page 87) under the
3D SETTING menu. Pressing the button again switches
to default display format.
DISPARITY SIM. (disparity simulation)
Press the button to change the phase of left/right signals
for 3D image display. You can monitor the depth of 3D
images using simulated 3D effect. Press the
+ or –
button to adjust the phase of the selected signal(s).
Select the signal(s) you want to adjust from
DISPARITY SIM. under the 3D SETTING menu before
using this function button. Pressing the button again
displays signals in their original phase.
GRID
Press the button to display a grid. The setting switches
ON t H GRID WIDTH t OFF with every press of
the button. You can adjust the grid width by pressing the
+ or – button.
