38
Control unit
Programming the transmitter
CH1
CH3
CH2
CH4
RADIO
INFORMATION!
If no transmission command is received within 30 seconds
of pressing the Radio button, the radio receiver switches
to normal operation.
1. Press the radio button repeatedly to select the required radio channel.
1 x 2 x 3 x 4 x
LED
CH 1
CH 2
CH 3
CH 4
2. Press the desired button on the transmitter until the previously selected
LED (CH 1, CH 2, CH 3, CH 4) goes out.
⇒ LED goes out - programming is complete.
⇒ The transmitter has transferred the radio code to the radio receiver.
3. Repeat the above steps to program additional transmitters.
INFORMATION!
Further transmitters cannot be programmed if all memory
positions of the handheld transmitter are occupied.
If the memory capacity has been reached
A total of 40 handheld transmitter commands are available for all channels.
If an attempt is made to program additional transmitters, the red LEDs of
radio channels CH 1 - CH 4 ash. If more memory positions are required,
see "Information on Memo" below.
Information on Memo
The memory capacity can be extended to 450 handheld transmitter
commands using the optional Memo accessory part. When plugging in the
Memo, all available transmitters are transferred from the internal memory
to the Memo and stored there. The Memo must remain plugged in on the
control unit.
No more transmitters are then stored in the internal memory. Stored
transmitters cannot be transferred from the Memo back to the internal
memory.
All radio channels, including the memory of the Memo, can be deleted;
see chapter "Deleting all radio channels in the receiver."
INFORMATION!
Delete the Memo on a new receiver.
Otherwise, all stored transmitters of an operator
are deleted and must be reprogrammed.
Cancelling programming mode
• Press the Radio button until all LEDs are o or make no input
for 30 seconds.
⇒ Programming mode is cancelled.
Deleting a transmitter button from the radio
channel
1. Press the radio button repeatedly to select the required radio channel.
Press and hold the Radio button for 15 seconds.
1 x 2 x 3 x 4 x
LED
CH 1
CH 2
CH 3
CH 4
⇒ The LED ashes after 15 seconds.
2. Release the Radio button.
⇒ The radio receiver is now in deletion mode.
3. Press the transmitter button for which the command is to be deleted
in the radio channel.
⇒ LED goes out
⇒ The deletion procedure has been completed.
• Repeat the process for additional buttons as required.
Deleting transmitter completely from the
receiver
1. Press and hold the Radio button for 20 seconds.
⇒ The LED ashes after 15 seconds
⇒ After another 5 seconds the ash sequence changes to blinking.
2. Release the Radio button.
⇒ The radio receiver is now in deletion mode
3. Press any button on the transmitter that is to be deleted.
⇒ The radio receiver is now in deletion mode
⇒ LED goes out
⇒ Deletion procedure has been completed
⇒ The transmitter is deleted from the radio receiver
• Repeat the process for additional transmitters as required.
