3.9 CT Connection
User Manual
3. Installation
CAUTION:
Make sure the AC cable is totally isolated from AC power before
connecting the or CT.
20
The CT provided in the product box is compulsory for hybrid system installation. It can be used
to detect the grid current direction and provide the system operating condition to hybrid inverter.
CT Model: ESCT-TA16-100A/50mA
CT Cable: Size – 2.3mm2, Length - 1m
Please install the CT on the hot line at the system grid connection point and the arrow on the
CT needs to point to the grid direction.
Lead the CT wires through the COM3 port at the bottom of the inverter and connect the CT
wires to the 16pin communication terminal block.
CT Wire
White
Pin 1 (From Left to Right)
Pin 2 (From Left to Right)
Pin 3 (From Left to Right)
Pin 4 (From Left to Right)
Pin 5 (From Left to Right)
Pin 6 (From Left to Right)
Black
Black
Black
16 PIN Communication Terminal Block
3.9.1 CT Installation
White
White
