TOOLS AND MATERIALS REQUIRED

• Tools to measure deadrise angle

• Timber to prepare fairing block for cutting, for example a 400 mm (16 in) length of 2×4 (2 in × 4 in, or

38 mm × 90 mm)

• Band saw or table saw, and appropriate safety equipment

• Drill and appropriate safety equipment

• Drill bit for pilot holes, appropriate for your hull’s construction material

• Hole saw: 19 mm (

¾ in)

• Hole saw: 38 mm (1

½ in)

• Deburring tool

• Detergent

• Sandpaper: 220–320 (ne)

• Sandpaper: 80–100 (coarse)

• Marine-grade adhesive sealant (below waterline use), such as Sikaex

291 or 3M™4200.

Approximately 150 mL (5  oz) per thru-hull installation

• Wrench: adjustable or 46 mm, for stem nut

• Allen key or hex drive: 3 mm

• Wrench: 17 mm

¼ Note: Two 17 mm wrenches (or one wrench and a deep socket) are used together to install M10 jam nut.
