4 While another person supports the transducer outside the hull, move inside the hull. Place the top half

of the fairing block in position over the stem and anti-rotation stud inside the hull. Conrm there are no

clearance issues.

⚠ WARNING: Do not install a mis-cut fairing block. Replace it instead.

5 While the dry t is in place, use masking tape to outline the top part of the fairing block where it

contacts the inner hull. (Leave a slight margin with the masking tape so the masking tape becomes the

boundary of the cured sealant.)

6 Outside the hull, with the bottom part of the fairing block in the correct position, use masking tape to

outline the fairing block on the hull. Leave a slight margin around the fairing block so the masking tape

becomes the boundary of the cured sealant.

7 Remove the transducer and fairing block parts from their test positions.

8 To ensure proper adhesion of the marine sealant, follow the manufacturer’s instructions to remove dirt,

grease, and anti-fouling coating from the installation areas you marked inside and outside the hull.

9 Use ne sandpaper (220–320) to sand inside the areas you marked. Make sure to wear appropriate

protective wear, and clean away dust resulting from drilling and sanding.
