1.3 TECHNICAL SPECIFICATIONS
MURELLE 70 BOX ErP
Heat output
Nominal (80-60°C) (Pn max) kW 63.2
Nominal (50-30°C) (Pn max) kW 68.1
Minimum (80-60°C) (Pn min) kW 13.4
Minimum (50-30°C) (Pn min) kW 15.0
Heat input (*)
Nominal (Qn max - Qnw max) kW 65.0
Minimum (Qn min - Qnw min) kW 14.0
Min/max operating yield (80-60°C) % 95.7/97.3
Min/max operating yield (50-30°C) % 107.4/104.8
Operating yield at 30% (40-30°C) % 108.1
Losses after shutdown to 50°C (EN 15502) W 156
Supply voltage V-Hz 230-50
Adsorbed power consumption (Qn max) W 186
Adsorbed power consumption (Qn min) W 128
Absorbed power IPX4D
Energy efficiency
Seasonal energy efficiency class of the heating system A
Seasonal energy efficiency of the heating system % 92
Sound power of the heating system dB (A) 65
Single module temperature regulation °C 20/80
Water content modules l 18.2
Max operating pressure (PMS) bar (kPa) 3.5 (343)
Max operating temperature (T max) °C 85
Exhaust temperature at nominal input (80-60°C) °C 86.6
Exhaust temperature at minimum input (80-60°C) °C 61.6
Exhaust temperature at nominal input (50-30°C) °C 55
Exhaust temperature at minimum input (50-30°C) °C 48
Maximum/Minimun exhaust capacity g/s 6.8/31.4
CO2 at input nominal/minimum (G20) % 9.0/9.0
CO2 at input nominal/minimum (G31) % 10.0/10.0
NOx measured (EN 15502-1:2015) mg/kWh 37
Maximum pressure exhaust manifold output Pa 160
PIN number 1312CT6271
Category II2H3P
Type B23-B53-B23P-B53P
NOx emission class (EN 15502-1:2015) 6 (‹ 56 mg/kWh)
Weight when empty kg 155
Gas and nozzle pressure
Supply pressure (G20) mbar (kPa) 20 (1.96)
Supply pressure (G31) mbar (kPa) 37 (3.63)
Number of nozzles n° --
Nozzle diameter (G20) ø --
Nozzle diameter (G31) ø --
Consumption at nominal power (G20) m
3
/h 6.87
Consumption at minimum power (G20) m
3
/h 1.48
Consumption at nominal power (G31) kg/h 5.04
Consumption at minimum power (G31) kg/h 1.08
(*) Heat input of the heating system measured using lower heating value (LHV)
