Je bekijkt pagina 18 van 56
18
NOTE: the inside of the upper door of the
generator panel has a label with the val-
ues that have to be set for PAR 1 and PAR
2 (fig. 19).
3.3.2 Warning
Should the generator operation not be opti-
mal but no alarm sets off, press the button
5
3
1
2
4
until info 70 and the warning code
associated to the ongoing event are dis-
played.
Once optimal operation is restored, info 70
will display: “- -”.
Below is the table of warning codes:
PARAMETERS INSTALLER
EXPANSION CARD
PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT
MEASUREMENT UNIT SETTING
40 Number of expansion boards 0 ... 3 = 1 0
41 Mix valve stroke time 0 ... 199 10 sec. 1 12
42 Priority of D.H.W. over mixed zone 0 = Paralle = = 1
1 = Absolute
43 Floor drying 0 = No activated = = 0
1 = Curve A
2 = Curve B
3 = Curve A+B
44 Type of solar system 1 ... 8 = 1 1
45 ∆t solar collector pump 1 PAR 74 OEM - 1... 50 °C 1 8
46 Solar integration delay “--”, 0 ... 199 Min. 1 0
47 Tmin solar collector “--”, -30 ... 0 °C 1 - 10
48 Tmax solar collector “--”, 80 ... 199 °C 1 120
PARAMETERS RESTORATION
PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT
MEASUREMENT UNIT SETTING
49 * Reset default parameters -- , 1 = = =
(par 01 - par 02 = “-“)
* In case of difficulty in understanding the current setting or in case of an anomalous or
incomprehensible conduct of the generator, we suggest to restore the initial values of the parameters
setting PAR 49 = 1 and the PAR 1 and PAR 2 as specified at point 3.3.1.
CODE DESCRIPTION
E0 Reduced capacity operation
(
∆
t between delivery and return
over 40°C)
E1 Shorted external sensor (SE)
E2 Preheating function active
E3 TBD
E4 TBD
E5 TBD
E6 TBD
E7 TBD
E8 TBD
E9 TBD
BOILER PAR 2
Instantaneous with diverter valve
and flowmeter
1
Instantaneous with diverter valve
flowmeter and solar combination
2
Remote control DHW cylinder
with diverter valve and cylinder
sensor vers. T (LOW INERTIA)
3
On board D.H.W. cylinder with
diverter valve and D.H.W. sensor
(LOW INERTIA)
4
Remote D.H.W. cylinder with
diverter valve and D.H.W.
thermostat or heating only vers.
T/R boiler
(LOW INERTIA)
5
On board D.H.W. cylinder with
double pump and D.H.W. sensor
vers. T/R boiler
(LOW INERTIA)
6
On board D.H.W. cylinder
with double pump and D.H.W.
thermostat vers. T/R boiler
(LOW INERTIA)
8
Heating only with
antifreeze
sensor
(LOW INERTIA)
9
