6. Operation
6.1. Safety Instructions for Operation
Attention
This device must be used only for the purposes it is designed for.
This device is intended for professional use as a battery-powered stage light effect. It can be installed only
indoors. This device is not suitable for households and for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
6.2. Control Modes
The Sonus Bar 4B can be controlled as a stand-alone device, in master/slave mode and with a DMX controller.
The Sonus Bar 4B supports the following control modes:
• Stand-alone: Auto mode, program mode, color mode, sound-controlled mode, IR remote control•
• Master/save: Auto mode, program mode, color mode, sound-controlled mode, IR remote control•
• DMX-512: RGBW (4 channels), Pixel (16 channels), Basic (6 channels), Extended (18 channels), Auto•
(6 channels), Basic Auto (10 channels), Extended Auto (22 channels)
For more information about how to connect the devices, refer to Setup (see 5. Setup on page 14).
To run the built-in programs in auto mode without a DMX controller:
01) Select one of the 3 auto programs in Auto Mode (see 6.7.1. Auto Mode on page 20).01)
02) Adjust the parameters of the selected auto program.02)
To run the built-in programs in program mode without a DMX controller:
01) Select one of the 24 built-in programs in Program Mode (see 6.7.2. Program mode on page 20).01)
02) Adjust the parameters of the selected built-in program.02)
To adjust the colors manually in color mode without a DMX controller:
01) Select one of the 4 colors in Color Mode (see 6.7.3. Color mode on page 21).01)
02) Adjust the dimmer value of the selected color.02)
To run the sound programs in sound-controlled mode without a DMX controller:
01) Select one of the 21 sound programs in Sound Mode (see 6.7.4. Sound Mode on page 21).01)
02) Adjust the parameters of the selected sound program.02)
To run the built-in programs in auto operation mode or in program mode, the sound-controlled mode or
manually control the colors with the IR remote control (see 6.8. Remote Control on page 27).
To operate the device with a DMX controller:
01) Select the DMX channel mode in the DMX Mode menu (see 6.7.7. DMX Mode on page 25).01)
02) Set the DMX starting address of the device in the DMX Mode menu (see 6.7.7. DMX Mode on page 25).02)
Refer to DMX Channels (see 6.9. DMX Channels on page 31) for a complete overview of all DMX channels.
17
c
Product code: 41275
Sonus Bar 4B
