Je bekijkt pagina 19 van 32
18
Ordercode: 40032
Phantom 180 Wash
DMX Channels
14 Channels
Channel 1 – Horizontal movement (Pan)
Move the fader up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0–255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 – Vertical movement (Tilt)
Move the fader up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0–255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 3 – PAN/TILT Speed
0–255
From Max Speed (0) to Min. Speed (255)
Channel 4 – Red color intensity CH10 must be open; CH11 must be set between 20–255
0–255
Gradual adjustment Red, from 0–100 %
Channel 5 – Green color intensity CH10 must be open; CH11 must be set between 20–255
0–255
Gradual adjustment Green, from 0–100 %
Channel 6 – Blue color intensity CH10 must be open; CH11 must be set between 20–255
0–255
Gradual adjustment Blue, from 0–100 %
Channel 7 – White color intensity CH10 must be open; CH11 must be set between 20–255
0–255
Gradual adjustment White, from 0–100 %
