19
Ordercode: 40032
Phantom 180 Wash
Channel 8 – LED built-in programs
CH10 must be open; CH11 must be set between 20–255, CH4–7 must be set between 0–255 (to set
the custom color for LED programs 1–7)
0–15
Not functional
16–31
LED program 1 (custom color)
32–47
LED program 2 (custom color)
48–63
LED program 3 (custom color)
64–79
LED program 4 (custom color)
80–95
LED program 5 (custom color)
96–111
LED program 6 (custom color)
112–127
LED program 7 (custom color)
128–143
LED program 8 (auto color)
144–159
LED program 9 (auto color)
160–175
LED program 10 (auto color)
176–191
LED program 11 (auto color)
192–207
LED program 12 (auto color)
208–223
LED program 13 (auto color)
224–239
LED program 14 (auto color)
240–255
LED program 15 (auto color)
Channel 9 – LED built-in program speed CH8 must be open
0–255
LED program speed, from slow to fast
Channel 10 – Dimmer intensity
0–255
Dimmer intensity, from dark to brightest
Channel 11 – Shutter/Strobe CH10 must be open; CH4–7 must be set between 0–255
0–19
Not functional
20–24
Shutter open
25–64
Strobe 1, from high to low frequency
65–69
Shutter open
70–84
Strobe 2 (slow close/fast open), from high to low frequency
85–89
Shutter open
90–104
Strobe 3 (fast close/slow open), from high to low frequency
105–109
Shutter open
110–124
Strobe 4 (random strobe), from high to low frequency
125–129
Shutter open
130–144
Strobe 5 (random slow close/fast open), from high to low frequency
145–149
Shutter open
150–164
Strobe 6 (random fast close/slow open), from high to low frequency
165–169
Shutter open
170–184
Strobe 7 (pulse strobe), from high to low frequency
185–189
Shutter open
190–204
Strobe 8 (random pulse strobe), from high to low frequency
205–209
Shutter open
210–224
Strobe 9 (fade in/fade out), from high to low frequency
225–229
Shutter open
230–244
Strobe 10 (random pulse), from high to low frequency
245–255
Shutter open
Channel 12 – Zoom
0–255
Gradual zoom adjustment, from big to small
