TM
USER MANUAL
DROP-IN ICE COOLED WELLS
OPERATING INSTRUCTIONS
FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL COULD RESULT IN SERIOUS INJURY OR DEATH.
General Information:
• Always clean equipment thoroughly before first use (see general cleaning instructions).
• Check rating label for your model designation.
• For best results, use stainless steel countertops.
General Operating Instructions:
• All foodservice equipment should be operated by trained personnel.
• Never hold perishable food above 41 degrees Fahrenheit (5 degrees Celsius).
Unboxing Instructions:
1. Remove unit from carton and all packaging materials from the unit.
2. Remove the manual/information packet from the unit.
3. Position the unit in desired location (refer to Installation Instructions).
NOTE: Place unit where the ambient air temperature is constant and a minimum of 70 degrees Fahrenheit and maximum
85 degrees Fahrenheit. Avoid areas that are subject to active air movements or currents. Make sure the unit is located on a
solid, level area at a proper height for convenient use and following health standards.
Setup & Operating Instructions:
1. Ensure unit is properly connected to a drain line, and a 1” IPS Ball Valve (not included) is in the “closed” position.
2. Fill the unit with ice, approximately ½ - ¾ of the total interior well.
3. Allow the unit 30 minutes to pre-chill.
NOTE: Covering the well will speed up the pre-chill time.
4. Place pre-chilled food or drinks in well.
5. Check well ice levels every 3 hours and refill as needed, drain excess water.
TOP
25 ⅞"
Ø1"
16 ½"
FRONT
11 /₁₆"
16 ½"
12 ⅞"
15 ¼"
1 /"
/"
SIDE
24 ⅝"
22 ¼"
25 ⅞"
10"
11 /"
1 /"
/"
TOP ICED FRONT SIDE
H H
A
C
B
D
E
H
H
E
B
D
C
Ball Valve
(Not Included)
6” Clearance
Recommended
Ball Valve
(Not Included)
FRONT SIDE
H H
A
A
C
B
D
E
H
H
ICE FILL
Ball Valve (Not Included)
in Closed Position
¾ Fill
½ Fill
TOP REFRIG
E
B
D
C
A
Recommended Fill Lines - Figure 1:
