DROP-IN ICE COOLED WELLS
USER MANUAL
INSTALLATION DIMENSIONS
DIMENSIONS BELOW ARE NOMINAL AND MAY VARY BASED ON MANUFACTURING TOLERANCES. IT IS RECOMMENDED TO
ALWAYS MEASURE THE ACTUAL UNIT RECEIVED PRIOR TO PROCEEDING WITH CUTOUT AND INSTALLATION.
Item #
Total Height
(Including
Drains)
Overall Outer Dimensions
(Flange)
Overall Outer Dimensions
(No Flange)
Suggested Cutout Size
Flange
Overhang
(Per Edge)
Width Depth Width Depth Width Depth
Diagram
Reference
A
B C D E F G
H
423SDI1A
11
1
/
16
"
(281mm)
16 ½"
(419mm)
25 ⅞"
(657mm)
15 ¼"
(387mm)
24 ⅝"
(625mm)
15 ½"
(394mm)
24 ⅞"
(632mm)
⅝"
(16mm)
423SDI2A
29 ⅝"
(752mm)
28 ⅜"
(721mm)
28 ⅝"
(727mm)
423SDI3A
42
13
/
16
"
(1087mm)
41
9
/
16
"
(1056mm)
41
13
/
16
"
(1062mm)
423SDI4A
56 ¼"
(1429mm)
55"
(1397mm)
55 ¼"
(1403mm)
423SDI5A
69 ⅞"
(1775mm)
68 ⅝"
(1743mm)
68 ⅞"
(1749mm)
423SDI6A
83
7
/
16
"
(2119mm)
82
3
/
16
"
(2088mm)
82
7
/
16
"
(2094mm)
INSTALLATION INSTRUCTIONS
Before getting started, please refer to the Installation Diagrams on page 6.
NOTE: Consult a qualified plumber for proper trap and drain installation that confirms to local plumbing codes.
1. Cut out countertop as specified.
NOTE: Unit is designed for installation in stainless steel countertops. If installed in stone or wood countertop, additional
clearances between the well and the counter are necessary.
2. Apply putty or butyl tape to the underside perimeter of the well rim outer edge.
3. Apply a ¼” bead of food-grade silicone adjacent to the putty/butyl tape on the well flange.
4. Drop well into the pre-cut opening from the top and push down until the perimeter of the well flange is flush with the
counter service.
5. Allow silicone to set and fully cure before making electric and water connections
6. Connect 1” IPS Ball Valve (not included) to drain line and connect drain line to waste line.
NOTE: Copper drain lines are recommended.
