XPT800 – Sound Level Meter and Spectrum Analyzer
V1.0
Page 35 of 124
5.4.5 Mounting on a tripod
To minimize operator influence on measurements, or in the case of measurements taken over long
periods, the instrument can be mounted on a standard camera tripod using the 1/4" threaded hole on
the back of the instrument, see “Fig. 1 - Hardware overview” on page 15.
5.5 Battery power supply
5.5.1 Battery power use
The instrument is supplied with the battery, already inserted in the battery compartment and with
the connector disconnected. Please refer to the “5.5.3 Battery insertion and replacement” on page 37
to make the correct connector connection.
The current battery voltage is displayed in the status bar, where there is a status icon with a battery
symbol. Battery discharge is displayed as a progressive emptying of the symbol.
•
When the remaining energy is less than about 15%, the battery status icon is empty (no notch).
•
A protection system prevents the instrument from making measurements with insufficient
charge levels and, if it is in measurement, performs the measurement stop automatically. If the
battery level drops further to the minimum level necessary to ensure functionality, the instru-
ment automatically shuts down.
•
When the battery voltage drops below 3.1 V, the sound level meter is unable to take measure-
ments. However, it is still possible to access the data in memory and perform data downloading.
Stored data and configuration and calibration parameters are retained even when the power
supply fails.
Battery charge indicator
The battery icon, found in the status bar, displays the charging status of the battery. When the in-
strument is charging or external power is being used, the background of the icon is orange.
Icon
Description
Icon
Description
85% ÷ 100%
15% ÷ 35%
60% ÷ 85%
0% ÷ 15%
35% ÷ 60%
Battery charging
