CBS- 880 INSTRUCTION MANUAL
19
Installing the Embossing Wheel (Optional Feature)
CBS-880 can be equipped with an optional embossing function. The embossing coder will continually emboss
characters directly on your bag. The coder uses pressure and does not use ink to print. The CBS-880 embossing
wheel is equipped for 1-line embossing with 15 characters. There are three sections so three sets of characters
are needed. Please note that all 15 characters in the three sections must be filled with a typeset. Optional feature:
2-line embossing which can be purchased separately.
1. Place the key in the groove of the embossing wheel plate and turn counter clockwise to loosen the wheel
plate. (Figure 13) Remove the embossing wheel plate, as well as the o-ring (Figure 14)
Figure 13
Figure 14
2. Carefully install typesets in each of the three cavities. Once all cavities are filled, place the O-ring and
wheel plate back in place. Using the key, carefully turn clockwise to lock wheel plate. Make sure none
of the typesets are pushed out of the cavity by holding the typesets in place as you turn the key.
Figure 15
Figure 16
3. Unscrew and remove the pattern knurled wheel on the sealer. Replace with the embossing wheel by
lifting the embossing wheel seat and pushing the embossing wheel in place. Please note: remove safety
cover before accessing the embossing wheel.
