CBS- 880 INSTRUCTION MANUAL
17
Figure 10. CBS-880 Temperature Controller
a. To set the temperature, press the SET button.
b. Press the <AT (auto tuning) button to move from the ones, tens, and hundreds place. Adjust
the value using the up and down arrows.
c. Press the SET button to save the temperature settings. Your desired temperature setting should
appear in green in the SV Value.
d. Wait until the PV temperature matches the SV temperature which should take approximately 5-
10 minutes.
e. Please note: Temperature will be in Celsius, not Fahrenheit. Do not attempt to make
additional adjustments to the temperature controller besides the temperature. The temperature
controller CANNOT be displayed in Fahrenheit and is ALWAYS in Celsius. Please do not
set the temperature controller above 200ºC. Please contact your local distributor if you need
assistance.
2. Place material on the guide (Figure 37 , Item #1) and allow the band sealer to pull your material through.
Make sure your material is flat on the guide. While the material is moving through the band sealer, do
not push or pull the material as this will cause irregular sealing.
PV
SV
°
C
SET
<AT
V
V
100s
10s
1s Place
100s
10s
1s Place
WARNING!
When the machine is running, do not put your hands near any of the wheels
and gears
WARNING!
When the machine is running, the temperature outside of the surface of the
heating block can reach over 400°F. Even after cooling down the machine,
the heating blocks will remain hot to touch.
