A1 A2 97 NO NC98 95 96
3/4
W9 1636671 01 A03
D
When motor current is less than minimum current setting
(< 0.5A), looping conductors through CT holes can
be used. The following table explains number of looping
for low current setting.
L1 L2
L3
96
95
98
97
A2
A1
E------
E---
Tr.
FUSE
MCCB
M
~3
OFF
(RESET)
START
13
14
KM1
KM1
A1
A2
KM1
LT47
TEST/STOP
RESET
Straight-through-Wiring
Line
Load
Line
Load
Looping Option (1-Loop)
When putting 2 ring lug in the same terminal,
plug one after the other as shown in figure.
2
1
3
Note:
b LT47 may be influenced by the
harmonics on the control power.
b The control power should be
supplied via the isolated transformer.
b Output: Normally energized.
No. of Loops
0
1
2
3
4
LT4706
Looping
Option
Time of Passing
1
2
3
4
5
Current Set. Range (A)
0.50 - 6.0 A
0.25 - 3.0 A
0.17 - 2.0 A
0.12 - 1.5 A
0.10 - 1.2 A
