HDPM6000 Installation Guide

Specifications

Electrical Characteristics

Measurement voltage

Per UL 61010-1: up to 277 VAC L-N / 480 VAC L-L

Per IEC 61010-1: up to 277 VAC L-N / 480 VAC L-L

Single phase 2-wire plus ground, 3-wire plus ground

or 4-wire plus ground

Specied accuracy range

108 VAC L-N / 187 VAC L-L to 332 VAC L-N / 576

VAC L-L

Continuous overload at voltage

measurement inputs

580 VAC L-L

Input frequencies 50 / 60 Hz

24 VDC power supplies input

voltage

100 to 240 VAC or 264 to 575 VAC to 24 VDC output

Measurement category CAT III

CT support

20 to 4000 A with internal burdened resister and

250 mV signal (no shorting blocks required)

CT options

Solid-core or split-core type current transformers with

a maximum voltage of 480 V

Supported protocols

Maximum number of

concurrent Modbus TCP

connections

Measurement Accuracy

The HDPM6000 Head Unit Real Energy (kWh) meets the accuracy limits of ANSI

C12.20 Class 0.5 and IEC 62053-22 Class 0.5S according to the following tests:

Measurement type

IEC 62053-22 2016

Class 0.5S

ANSI C12.20-2010

Class 0.5

Variation of Current



Equality of Circuits

 

Variation of Voltage

 

Variation of Frequency

 

Variation of Ambient

Temperature

 

Load Performance



Variation of PF



Environmental Characteristics

Operating temperature -20 to 60 °C (-68 to 140 °F)

Storage temperature -40 to 85 °C (-40 to 185 °F)

Relative humidity 5 to 90% non-condensing

Maximum operating altitude 2,000 m (6,562 ft.)

Non-operating altitude 15,000 m (49,213 ft.)

Noise level < 65 dba at six ft. (72 in.) from the HDPM6000

Mounting location Not suitable for wet locations. For indoor use only.

Pollution degree 2
