Introduction Low Power
Introduction
These pressure transmitters measure pressure by applying the pressure to a
piezoresistive silicon microsensor within the sensor assembly. The microsensor
converts the pressure to a change in resistance, and the resistance change is
converted to a 1 to 5 V dc signal that is proportional to the pressure.
• Absolute pressure transmitters measure pressure relative to vacuum. Gauge
pressure transmitters measure pressure relative to ambient air pressure. Both
absolute and gauge transmitters are used in a wide variety of oil, gas, water and
industrial applications.
• Differential pressure transmitters measure the difference between two pressures
applied to opposite sides of the sensor. The output signal is proportional to either
the differential pressure or its square root.
Differential pressure transmitters are often used for measuring fluid flow rates
across a primary device such as an orifice plate, but can also be used for other
types of differential pressure measurements such as liquid level, interface level,
or density measurements.
The pressure transmitter can be supplied with direct-connect or remote pressure
seals to isolate the measuring element from corrosive or viscous fluids.
Reference Documents
Document Description
Instructions
MI 020-611 Absolute, Gauge, and Differential Pressure Transmitters with HART Communication
and SIL 2
MI 020-612 Absolute, Gauge, and Differential Pressure Transmitters with FOUNDATION
Fieldbus Communication
MI 020-613 Absolute, Gauge, and Differential Pressure Transmitters with Low Power
MI 020-328 Bubble Type Installation for Liquid Level
MI 020-329 High Accuracy Flow Measurement
MI 020-369 Pressure Seals
MI 020-543 FM/CSA Safety Information
MI 020-544 ATEX/IECEx Safety Information
MI 022-138 Bypass Manifolds - Installation and Maintenance
MI 022-335 Model CO Compact Orifice
Dimensional Prints
DP 020-342 PSFLT Pressure Seals
DP 020-343 PSFPS and PSFES Pressure Seals
DP 020-345 PSFAR Pressure Seals
DP 020-346 PSFAD Pressure Seals
DP 020-347 PSTAR Pressure Seals
DP 020-348 PSTAD Pressure Seals
DP 020-349 PSISR Pressure Seals
DP 020-350 PSISD Pressure Seals
DP 020-351 PSSCR Pressure Seals
DP 020-353 PSSCT Pressure Seals
MI 020-613 9
