1757361 06/2012 5

Steps for setting up the braking unit

Steps 1 to 4 must

be performed with

the power off

b 1 Take delivery of the braking unit (see page 13)

v Check that the catalog number printed on the label is the same

as that on the purchase order.

v Remove the braking unit from its packaging and check that it has

not been damaged in transit.

b 2 Check the line voltage (see page 14)

v Check that the line voltage is compatible with the voltage

range of the braking unit

b 3 Install the braking unit (see page 21)

v Mount the braking unit in accordance with the

instructions in this document

v Install any internal and external options

b 4 Wire the braking unit (see page 23)

v Connect the braking unit to the 3-phase supply

(L1,L2,L3)

v Connect the braking unit to the drive DC bus

Connect the control cable
