Characteristics

General characteristics

Electrical characteristics

Connection characteristics

Degree of protection IP 20

Maximum relative humidity Class F humidity without condensation 5…85%

Ambient temperature

around the unit

Operation °C (°F) 5…+ 40 (41…+ 104) without derating

Up to 55°C (131°F) with current derating of 3% per °C (34°F) above 40°C (104°F)

Storage °C (°F) - 25…+ 55 (-77…+ 131)

Maximum operating altitude m 1000 without derating

1000…4000 derating the current by 5% per additional 1000 m

Type of module VW3 A7 201…212 VW3 A7 231…241

Supply voltage V a 400 a 460

Nominal voltage ± 10% V a 380…415 a 440…480

Operating frequency Hz 40…60 ± 10%

Overload capacity A 1.2 x maximum current (Irms)

Efficiency 97% (3% of thermal losses)

Power factor 1

Fundamental frequency component 0.7…0.95

Type of module Maximum wire size

VW3 A7 201 25 mm

, connected on a bar, M5

VW3 A7 202…205,

VW3 A7 231, 232

35 mm

, connected on a bar, M6

VW3 A7 206…209,

VW3 A7 233…238

95 mm

, connected on a bar, M8

VW3 A7 210…212,

VW3 A7 239…241

150 mm

, connected on a bar, M10
