1760917 11/2009 3

Preface

Thank you for purchasing Remote Keypad (VW3A21101) for Altivar 21 series inverters. Using this

product, panel operation, display and adjustment of the inverter can be remotely controlled from up to

5 meters away. You can copy data from one place to another and then execute data comparison

between the inverter and the memory of Remote Keypad or between the memories of Remote

Keypad itself.

Before using Remote Keypad, carefully read this instruction manual in order to completely and

correctly utilize Remote Keypad’s excellent performance.

After reading this instruction manual, please keep it handy for future reference.

- Accessory check list

Remote Keypad is shipped together with the following accessories.

On opening the packing case, check to see if the following accessories are contained or not.

(1) Instruction sheet .............................................. 1 copy

(2) Mounting screws (M3 x 12mm) ....................... 4pcs.

(M3 screw tightening torque: 0.6 Nּm)

(3) Connection cable between an inverter and Remote Keypad. Length: 3 meters.

Instruction

Sheet
