4.3.5. Memory initializing function “clr”

A selected one of the memories either memory A, B, C of Remote Keypad is enable to be initialized

with this function. In addition, all memories including system memory of Remote Keypad is also

enable to be initialized.

Operating procedure

Key LED indication

Key operation and description

SFT

“copy” → “comp”

→ “prot” → “clr”

< Selecting a desired function >

Select “

clr” (memory initializing function) with the [SFT] key.

ENT

“clr” → “a”

< Entering the selected function >

After selecting “

clr” with the [SFT] key, press the [ENT] key and

“

a” (selecting memory A) appears in the display window.

SFT

“a” → “b” → “c

→ “sys” → “a”

< Selecting a memory to initialize >

Each time the [SFT] key is pressed, the display changes as follow

“

a” selecting memory A

“

b” selecting memory B

“

c” selecting memory C

“

sys” selecting all memories (reprogram to default setting)

and to “

a” again in this order.

ENT

“a” → “off”

< Entering the memory to initialize >

After selecting a memory for initialization (selecting memory A, by

way of example) with the [SFT] key, press the [ENT] key and “

off”

appears in the display window.

SFT

“off” → “on”

→ “off”

< Initializing the selected memory >

Each time the [SFT] key is pressed, the display changes

“

on”(to initialize selected memory)

“

off” (not to initialize the selected memory).

alternately.

ENT

“on” → “init”

→ “clr”

< Executing initialization of the selected memory >

After selecting “

on” with the [SFT] key, press the [ENT] key and

Remote Keypad starts initializing the selected memory with the

indication “

init” appearing in the display window. When the

initialization of the selected memory is complete, the indication in the

display window returns to “

clr”.

- If the [ESC] key is pressed, Remote Keypad returns to previous status (except when executing).

- When the memory protection function is actuated, Remote Keypad prohibits the initialization of memory with

“

prot” appearing in the display window.
