1760917 11/2009 8

4. Functions in detail

Remote Keypad can be used as remote operation panel (“REMOTE KEYPAD MODE”) or parameter

back-up device (“COPY MODE”). When the “COPY MODE” led is lit when turning power on, Remote

Keypad operates in “COPY MODE”, otherwise in “REMOTE KEYPAD MODE”.

4.1. Procedure to switch the operation mode

According to the procedure described in “3. Connection and start-up”, turn on the power of Remote

Keypad while holding down the [ENT] key of Remote Keypad. Operation mode changes.

4.2. “REMOTE KEYPAD MODE”

In “REMOTE KEYPAD MODE”, operation is the same as operation on the panel of the inverter. For

details, see instruction manual of the inverter. Data entered through Remote Keypad takes priority

over data entered through the inverter’s control panel. However, if Remote Keypad is deactivated by

an unexpected event such as an abnormality, the inverter’s input keys remain functional.

4.3. “COPY MODE”

In “COPY MODE”, storing and loading the parameters are permitted. Editing the parameters is not

permitted.

Operating procedure

Key LED indication

Key operation and description

―――――

“chc ”→“init”

→“c0py”

When “COPY MODE” is initiated, “chc” is shown in the display

window. This is followed by “

init” to indicate that the power

supply is being initialized. Finally, when ready to use the display

shows “

EQR[”.

SFT

“c0py”→“c0mp”

→“pr0t”→“clr”

→“f- ”→“c0py”

< Selecting a desired function >

Select the function with the [SFT] key. Each time the [SFT] key is

pressed, indication on the display changes from “

copy” (copying

function) to “

comp” (comparing function), to “prot” (memory

protecting function), to “

clr” (memory initializing function), to

“

f- ” (Remote Keypad parameter editing function), and finally

back to “

copy” again in this order.
