www.scheppach.com
GB
|
31
Place all supplied parts on a at surface. Group equal
parts.
Note: If connections are secured with a screw (round
head/or hexagon), hexagonal nuts and washer, the
washer must be placed under the nut.
Insert screws each from outside to inside. Secure con-
nections with nuts on the inside.
Note: During assembly, tighten the nuts and bolts only
to the extent that they cannot fall off.
If you tighten the nuts and screws fully before nal as-
sembly, it is not possible to complete the assembly.
Fig. 1
• Place the tabletop (1) on a workbench (remove pack-
ing pad (a) under the motor).
Fig. 1.1
• Mount the frame leg (2) to the tabletop (1) with 2 M6
x 16 hexagonal bolts, 2 washers 6 and 2 M6 nuts.
Fig. 2
• Mount the switch (6) to the tabletop (1) with 2 M6 x 16
hexagonal bolts, 2 washers 6 and 2 M6 nuts.
Fig. 3
• Mount the frame leg (3) to the tabletop (1) with 2 M6
x 16 hexagonal bolts, 2 washers 6 and 2 M6 nuts.
Fig. 4
• Mount the frame leg (4) to the tabletop (1) with 2 M6
x 16 hexagonal bolts, 2 washers 6 and 2 M6 nuts.
Fig. 5
• Mount the frame leg (5) and the hose holder (b) to
the tabletop (1) with 2 M6 x 16 hexagonal bolts, 2
washers 6 and 2 M6 nuts.
Fig. 6 / 6.1
• Mount 2 longitudinal struts (10) and 2 cross mem-
bers (9), to the frame legs (2, 3, 4 and 5) with 12
M6 x 16 hexagonal bolts, 12 washers 6 and 12 M6
hexagonal nuts.
Fig. 7 / 7.1 / 7.2 / 7.3
• Mount the table extension plate (8), with two struts
(11), to the tabletop and cross member with 6 M6 x
16 hexagonal bolts, 6 washers 6, and 6 M6 hexag-
onal nuts.
8. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m ATTENTION!
The device and the packaging material are not
children’s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suffocating!
9. Attachment and operation
Before commissioning
• Prior to commissioning, all covers and safety devic-
es must be mounted correctly.
• It must be possible for the saw blade to run freely.
• In case of previously machined wood, be aware of
any foreign bodies, such as nails or screws, etc.
• Before pressing the on/off switch, make sure that the
saw blade is correctly tted, and that moving parts
run smoothly.
• Before connecting the machine, make certain that
the data on the type plate matches with the mains
power data.
• Only connect the machine to a correctly installed
protective contact socket, with fuse protection of at
least 16A.
Attachment and operation
Attention! Remove the mains plug before any mainte-
nance, modication and assembly work on the circular
saw.
