www.scheppach.com
30
|
GB
• Residual risks can be minimised if the “Safety in-
structions” and the “Proper use” are observed along
with the whole of the operating instructions.
• Do not unnecessary stress the machine: too much
pressure when sawing will damage the saw blade
quickly. This results in reduced output of the ma-
chine in the processing and in cut precision.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual. In
doing so, your saw provides optimal performance.
• Keep your hands away from the work area, when the
machine is in operation.
• Before maintaining or adjusting, switch off the machine
and unplug the power plug.
7. Technical data
AC motor 230 V~ 50 Hz
Power 2200 W
Operating mode S6 40%
Idle speed 2800 min
-1
Carbide saw blade Ø 315 x Ø 30 x 3 mm
Number of teeth 24
Table size 800 x 550 (950) mm
Cutting height max. 90° 83 mm
Cutting height max. 45° 53 mm
Height adjustment 0 - 83 mm
Tilting saw blade 0 - 45°
Weight approx. 48 kg
Technical changes reserved!
Noise and vibration
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Noise data
Sound power level L
wA
105,2 dB(A)
Sound pressure level L
pA
90,2 dB(A)
Uncertainty K
wA/pA
3 dB(A)
m WARNING! This power tool generates an electro-
magnetic eld during operation. This eld can impair
active or passive medical implants under certain con-
ditions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical im-
plants consult with their physician and the manufactur-
er of the medical implant prior to operating the power
tool.
Safety instructions for the handling of saw blades
1. Only use insertion tools if you have mastered their
use.
2. Observe the maximum speed. The maximum
speed specied on the insertion tool may not be
exceeded. If specied, observe the speed range.
3. Observe the motor / saw blade direction of rota-
tion.
4. Do not use any insertion tools with cracks. Sort out
cracked insertion tools. Repairs are not permitted.
5. Clean dirt, grease, oil and water off of the clamping
surfaces.
6. Do not use any loose reducing rings or bushes to
reduce holes on circular saw blades.
7. Make sure that xed reducer rings for securing the
insertion tool have the same diameter and have at
least 1/3 of the cutting diameter.
8. Make sure that xed reducer rings are parallel to
each other.
9. Handle insertion tools with caution. They are ide-
ally stored in the originally package or special con-
tainers. Wear protective gloves in order to improve
grip and to further reduce the risk of injury.
10. Prior to the use of insertion tools, make sure that
all protective devices are properly fastened.
11. Prior to use, make sure that the insertion tool
meets the technical requirements of this electric
tool and is properly fastened.
12. Only use the supplied saw blade for cutting wood,
never for the processing of metals.
6. Residual risks
The electric tool has been built according to state-
of-the-art and the recognised technical safety rules.
However, individual residual risks can arise during op-
eration.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
