www.scheppach.com
36
|
GB
• Due to protective coating on the engine, a small
amount of smoke may be present during the initial
use of the device and should be considered normal.
This is a normal process.
•
m Attention!
• Never allow the pull cable starter to snap back.
• Attention: In case of cool weather, it may be neces-
sary to repeat the starting process numerous times.
Switch the engine o:
• To turn o the engine, release the drive lever (2),
then the engine brake lever (3) and wait for the
blades to stop.
• Pull the spark plug connector o the spark plug (10)
to prevent unintentional start of the engine.
• Before you start the engine again, check the cable
for the engine brake. Check that the cable is correct-
ly tted. If the cable is kinked or damaged, it should
be replaced.
• Remove the battery. The battery is the device key
on some models.
Before mowing
Important notes:
• Dress appropriately. Wear sturdy shoes and no san-
dals or trainers.
• Check the cutting blade. If a blade is bent or other-
wise damaged, it must be replaced with an original
blade.
• Only ll the fuel tank outdoors. Use a lling funnel
and a measuring jug. Wipe o any spilled petrol.
• Read and follow the operating instructions and also
the instructions regarding the engine and the acces-
sories. Keep the manual accessible for other users
of the device.
• Exhaust gas is dangerous. Only start the engine
outdoors.
• Make sure that all safety devices are in place and
working properly.
• The device should only be operated by a person who
is capable of doing so.
• Mowing wet grass can be dangerous. Mow grass
when it is as dry as possible.
• Instruct other persons or children to stay away from
the mower.
• Never mow when visibility is poor.
• Pick up loose objects lying around, such as stones,
toys, sticks and wires, etc., from the ground before
mowing.
Warning: The cutting blade rotates when the engine
is started.
Important: Before starting the engine, move the en-
gine brake several times to check that the stop cable is
also working well.
Note: The engine is designed for cutting speed for
grass, and grass ejection into the catcher box and for
a long engine life.
• Check the oil level.
• Open the fuel cap and ll the fuel tank (6) up to the
lower point of the tank inlet with about 1.4 litres of
petrol. Use a funnel and measuring container for ll-
ing. Do not overll the tank. Only use fresh, clean,
unleaded fuel.
• Never mix oil with petrol. Purchase fuel in quantities
that can be used within 30 days to ensure that the
fuel is fresh.
Note: Use standard unleaded petrol with max. 10%
bioethanol component.
m WARNING
Always only use a safety petrol canister. Do not smoke
when lling petrol. Remove any residual oil and petrol
Switch the engine o before lling petrol and let the en-
gine cool for several minutes.
Starting the engine (Fig. 14a)
• Check the motor oil level. See “oil level check” section.
• Inspect the battery compartment at the top of the
engine for foreign objects and clean with a brush
or cloth if necessary. Install the battery in the motor
battery compartment at the top of the engine. Make
sure that the battery is securely fastened. The bat-
tery is the device key on some models.
• Make sure that the controls for the device drive, if any,
are out of operation.
• Model with electric starter (17a). Press the safety bar
(3) against the handlebar. Operate the electric start-
er. The engine will start.
Start the engine (Fig. 14)
• Make sure that the device is connected properly to
the spark plug.
• Stand behind the mower. One hand pushes the en-
gine brake lever (3) to the handle, the other hand
should be on the pull starter.
• Start the engine with the pull starter (17). To do this
pull the handle approx. 10 – 15 cm (until you feel a re-
sistance) and then start the engine with a sharp pull.
If the engine does not start, pull on the handle again.
