www.scheppach.com
GB
|
37
Regularly check that the blade is properly fastened, in
good condition and sharpened. Sharpen or replace it if
this is not the case. If the moving blade strikes an object,
stop the mower and wait for the blade to come to a com-
plete stop. Then check the condition of the blade and the
blade holder. If it is damaged, it must be replaced.
Tips for mowing:
• Pay attention to ensure that you do not run into or
over solid objects. The lawnmower could be dam-
aged and/or the machine could inict bodily injury.
• A hot engine, exhaust pipe or drive unit can burn the
skin. Thus, do not touch these parts.
• Use extra caution when mowing on inclines and
steep grades.
• Only mow when there is sucient light.
• Check the mower, the blade and other parts if they
have struck a foreign object or if the machine vibrates
more than usual.
• Do not make any adjustments or repairs until the en-
gine has been switched o. Pull o the spark plug
connector.
• Pay special attention to trac if you are mowing di-
rectly next to a street or are close by one. Always
keep the grass chute pointed away from the street.
• Avoid mowing in places where the wheels have trou-
ble gripping or mowing is unsafe in any other way.
Before you back up, ensure that nobody is standing
behind you (especially little children).
• In dense, tall grass, set the highest cutting level and
mow more slowly. Before you remove any grass or
blockages of any kind, switch o the engine and dis-
connect the ignition cable.
• Never remove any safety-related parts.
• Never ll the engine with petrol when it is hot or is
running.
Emptying the catch basket
As soon as grass residues are left lying behind on the
ground during mowing, the catch basket must be emp-
tied.
m WARNING
Before removing the catch basket, stop the engine
and wait for the cutting tool to come to a standstill.
To remove the catch basket (16), lift the discharge ap
(15) with one hand and remove the catch basket (16)
by the carrying handle with the other hand (Fig. 16). In
accordance with the safety regulations, the discharge
ap (15) closes when the catch basket is unhooked and
closes the rear ejection opening.
Hints for mowing correctly
m Attention! Never open the discharge ap when
the catcher is being emptied and the engine is still
running. The rotating blade can lead to injuries.
Always secure the discharge ap and the catch basket
carefully. Switch o the engine before removing.
The safety distance between the blade housing and
the user given by the guide rails must always be main-
tained. Special care must be taken when mowing and
changing direction on embankments and slopes. Make
sure you have a secure footing, wear shoes with non-
slip, well gripping soles and long trousers. Always mow
across slopes.
For safety reasons, slopes with an inclination of more
than 15 degrees must not be mowed with the lawn
mower.
Exercise particular caution when moving backwards
and pulling the lawnmower. Risk of tripping!
Mulching
When mulching, the cuttings are shredded in the
closed mower housing and then dispersed on the lawn.
Grass collection and disposal is not required.
m NOTE! Mulching is only possible on relatively short
lawns.
To use the mulching function, unhook the catch basket
(16) and slide the mulching adapter (Fig.10-12 / 19) into
the discharge opening and close the discharge ap (15).
Mowing
Cut only with sharp, clean cutting blades so that the
blades of grass do not fray and the lawn does not turn
yellow.
To achieve a clean cut, guide the lawnmower in the
straightest possible paths. These strips should always
overlap by a few centimetres so that no patches remain.
Keep the underside of the mower housing clean and
remove any grass deposits. Deposits make the starting
process more dicult, impair cutting quality and grass
discharge. On slopes, the cutting path should be made
perpendicular to the slope. It is possible to prevent the
lawnmower from slipping by lifting it upwards at an
angle. Set the cutting height depending on the actual
length of the lawn. Carry out several passes so that a
maximum of 4 cm of lawn is removed at a time. Switch
o the engine before carrying out any checks on the
blade. Remember that the blade will continue to rotate
for a few seconds after the engine is switched o. Never
try to stop the blade.
