• Keep your hands away from the working area when
the product is in operation.
• Damage to hearing if the stipulated hearing protection
is not worn.
• Damage to the lungs if the stipulated respiratory pro-
tection is not worn.
• Risk of injury from tools thrown away due to improper
holding or guiding.
• Health hazard due to electrical power, with the use of
improper electrical connection cables.
• Avoid accidental start-up of the product: when insert-
ing the plug into the socket, do not press the on/off
switch.
• Before performing setting or maintenance work, re-
lease the on/off switch and pull out the mains plug.
WARNING
This power tool generates an electromagnetic field
during operation. This field can impair active or passive
medical implants under certain circumstances. In order
to prevent the risk of serious or deadly injuries, we rec-
ommend that persons with medical implants consult
with their physician and the manufacturer of the medical
implant prior to operating the power tool.
WARNING
In case of extended working periods, the operating per-
sonnel may suffer circulatory disturbances in their
hands (vibration white finger) due to vibrations.
Raynaud's syndrome is a vascular disease that causes
the small blood vessels on the fingers and toes to
cramp in spasms. The affected areas are no longer
supplied with sufficient blood and therefore appear ex-
tremely pale. The frequent use of vibrating products can
cause nerve damage in people whose circulation is im-
paired (e.g. smokers, diabetics).
If you notice unusual adverse effects, stop working im-
mediately and seek medical advice.
6 Technical data
AC motor 230 - 240 V~ 50 Hz
Power consumption 350 Watts (S1*)
450 Watts (S2 20 min**)
Idle speed n
0
1400 rpm
Band saw blade length 1400 mm
Band saw blade width 6 mm
Max. band saw blade width 12 mm
Band saw blade speed 900 m/min
Cut height 0 - 80 mm
Swing 200 mm
Saw table size 300 x 300 mm
Inclinable saw table 0° - 45°
Max. workpiece size 400 x 400 x 80 mm
Weight approx. 14.8 kg
Subject to technical changes!
*Operating mode S1 (continuous operation)
The product can be operated continuously with the speci-
fied power.
**Operating mode S2 (short-term operation)
The product may only be operated at the specified power
for a brief time (20 min.).
The workpiece must have a minimum height of 3mm
and a minimum width of 10mm.
Noise data
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841.
Sound pressure level L
pA
77.4 dB
Uncertainty K
pA
3 dB
Sound power level L
wA
90.4 dB
Uncertainty K
wA
3 dB
The specified noise emission values have been measured
in accordance with a standardised test procedure and can
be used to compare one power tool with another.
The specified device emissions values can also be used
for an initial estimation of the load.
WARNING
The noise emission values can vary from the
specified values during the actual use of the
power tool, depending on the type and the
manner in which the electric tool is used, and
in particular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
GB | 27www.scheppach.com
