Battery charger
Input
Rated voltage 220 – 240 V~/50-60Hz
Rated power consumption 50 W
Fuse (internal) 2 A
Output
Rated voltage 12 V
Rated current 2.4 A
Protection class II (Double insulation)
Loading time:
1.3 Ah approx. 60 min
Battery (Li-Ion)
Number of battery cells 3
Rated voltage max. 12 V
Capacity 1.3 Ah
Power 15.6 Wh
Max. temperature. 50°C
Charging process temperature 4 °C – 40 °C
Operation temperature -20 °C – 50 °C
Storage temperature 0 °C – 45 °C
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Noise data
Sound pressure L
pA
71 dB
Measurement uncertainty K
pA
5 dB
Sound power L
wA
82 dB
Measurement uncertainty K
wA
5 dB
Vibration parameters (hand/arm vibration)
Vibration a
h
< 1.987 m/s
2
Measurement uncertainty K 1.5 m/s
2
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the electric tool is used, and in par-
ticular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Before commissioning
8.1 Wall mounting of the charger (12)
(Fig. 1)
WARNING
– Before wall mounting, make sure that there are no
lines in the wall in the area of the drill holes that
could be damaged.
– Lay the mains cable so that it does not obstruct you
and no one can accidentally pull on it.
– Children must not play with the product, even if it is
hanging on the wall.
– Mounting behind doors and their swinging range is
not recommended, as there is a risk of tearing off or
otherwise damaging the product.
GB | 21www.scheppach.com
