GB
|
39
• Start the mower and switch o after approx. 30 sec.
The rotating blade bar dashes the water against the
underside of the mower and in doing so cleans it.
• Close the water tap and disconnect the hose-con-
nection piece.
• Clean the top side with a cloth (do not use sharp
objects).
11. Transport
Preparing the lawnmower for transport (Fig. 22)
• Empty the fuel tank (6) with a petrol extraction
pump.
• Always let the engine run until it has used up the
remainder of petrol in the tank.
• Drain the motor oil of the warm motor.
• Remove the spark plug connector from the spark
plug (10).
• Clean the cooling ns of the cylinder and the hous-
ing.
• Remove the pull cable starter (17) from the hook.
Release the quick clamp levers (5) and fold down
the upper push bar (4). Make sure that the cables
are not bent during this process.
• Wedge a few layers of corrugated cardboard be-
tween the upper and lower push bars and the en-
gine to prevent any chang.
12. Storage
Store the device and its accessories in a dark, dry
and frost-free place that is inaccessible to children.
The optimum storage temperature lies between 5 and
30 ˚C.
Store the tool in its original packaging.
Cover the tool to protect it from dust or moisture.
Store the operating manual with the tool.
• Never store the lawnmower with petrol in the tank
inside a building in which petrol fumes may come
into contact with naked ames or sparks.
• Allow the engine to cool down before you put the
lawnmower in an enclosed area.
• In order to avoid re hazards, keep the engine, ex-
haust pipe and the area around the fuel tank free of
grass, leaves and leaking grease (oil).
Preparing the lawnmower for long-term storage
Warning: Do not remove the petrol in enclosed spac-
es, near re or when smoking. Petrol fumes can
cause explosions and re.
• Empty the fuel tank with a petrol extraction pump.
• Start the engine and let it run until the remaining
petrol is used up.
• Change the oil at the end of every season. To do
so, remove the used engine oil from a warm engine
and rell with fresh oil.
Lift the discharge ap (15) with one hand and hold the
catch basket (16) by the handle with the other hand
and hook it in from above. (Fig. 9)
After mowing
• Always allow the motor to cool o before parking
the lawnmower in an enclosed room. Remove
grass, leaves, grease, and oil before storage. Do
not store other objects on the mower.
• Check all screws and nuts before the next use.
Tighten all loose screws.
• Empty the catch basket (16) before the next use.
• Remove the spark plug connector to prevent unau-
thorised use.
• Make sure that the mower is not parked next to a
source of danger. Escaping gas can cause explo-
sions.
• Only original parts or parts approved by the man-
ufacturer may be used for repairs (see address on
guarantee certicate).
• In case of longer idle periods of the mower, empty
the petrol tank with a petrol extraction pump.
• Oiling and servicing the device
10. Cleaning
The mower should be thoroughly cleaned after each
use. In particular, the underside and the blade retain-
er.
m Attention!
For safety reasons, disconnect the spark plug cable
before cleaning.
It is best to tilt the mower backwards. The spark plug
(10) should point upwards to prevent engine oil from
entering the intake tract or leaking out.
Alternatively, you can tilt the device on its side, but
you must make sure that the air lter (7) is on the
upper side.
Note: Before tilting the lawnmower, empty the fuel
tank (6) fully with a petrol extraction pump.
Do not tilt the lawnmower beyond 90 degrees.
It is easiest to remove the dirt and grass immediately
after mowing.
Grass residues and dirt that have dried on can impair
mowing. Check that the grass ejector tube is clear of
grass residue and clear it out if necessary.
Never clean the mower with a water jet or high pres-
sure cleaner. The motor should remain dry.
Do not use aggressive cleaning products such as
cold cleaners or white spirit.
Clean the device with water as follows.
• Remove the mulch insert / take o the grass bag.
• Attach the hose-connection piece to the mower (w)
and open the water tap. (Fig. 24)
