GB
|
37
• Due to protective coating on the engine, a small
amount of smoke may be present during the initial
use of the device and should be considered nor-
mal. This is a normal process.
•
m Attention!
• Never allow the pull cable starter (17) to snap back.
• Attention: In case of cool weather, it may be nec-
essary to repeat the starting process numerous
times.
Switching the engine o:
• To stop the engine, release the drive lever (2) then
the engine brake lever (3) and wait until the blade
stops.
• Pull the spark plug connector o the spark plug (10)
to prevent unintentional start of the engine.
• Before you start the engine again, check the cable
for the engine brake. Check that the cable is cor-
rectly tted. If the cable is kinked or damaged, it
should be replaced.
• Remove the battery (20). The battery (20) is the de-
vice key on some models.
Before mowing
Important notes:
• Dress appropriately. Wear sturdy shoes and no
sandals or trainers.
• Check the cutting blade. If a blade is bent or other-
wise damaged, it must be replaced with an original
blade.
• Only ll the fuel tank (6) outdoors. Use a lling fun-
nel and a measuring jug. Wipe o any spilled petrol.
• Read and follow the operating instructions and also
the instructions regarding the engine and the ac-
cessories. Keep the manual accessible for other
users of the device.
• Exhaust gas is dangerous. Only start the engine
outdoors.
• Make sure that all safety devices are in place and
working properly.
• The device should only be operated by a person
who is capable of doing so.
• Mowing wet grass can be dangerous. Mow grass
when it is as dry as possible.
• Instruct other persons or children to stay away from
the mower.
• Never mow when visibility is poor.
• Pick up loose objects lying around, such as stones,
toys, sticks and wires, etc., from the ground before
mowing.
Hints for mowing correctly
m Attention! Never open the discharge ap when
the catcher is being emptied and the engine is
still running. The rotating blade can lead to in-
juries.
Release the driver lever (2) in time to stop the mov-
ing lawn mower. Practice starting and stopping be-
fore you use the mower for the rst time until you
are familiar with controlling the mower.
Warning: The cutter blade rotates when the engine
is started.
Important: Before starting the engine, move the en-
gine brake lever (3) several times to check that the
stop cable is also working well.
Note: The engine is designed for cutting speed for
grass, and grass ejection into the catcher box and for
a long engine life.
• Check the oil level.
• Open the fuel fuel cap and ll the fuel tank (6) up to
the lower point of the tank inlet with about 1.4 litres
of petrol. Use a funnel and measuring container
for lling. Do not overll the fuel tank (6). Only use
fresh, clean, unleaded fuel.
Never mix oil with petrol. Purchase fuel in quanti-
ties that can be used within 30 days to ensure that
the fuel is fresh.
Note: Use standard unleaded petrol with max. 10%
bioethanol component.
m WARNING
Always only use a safety petrol canister. Do not smoke
when lling petrol. Remove any residual oil and petrol
Switch the engine o before lling petrol and let the
engine cool for several minutes.
Starting the engine (Fig. 14a)
• Check the motor oil level. See “oil level check” sec-
tion.
• Inspect the battery compartment at the top of the
engine for foreign objects and clean with a brush or
cloth if necessary. Install the battery (20) in the en-
gine battery compartment at the top of the engine.
Make sure that the battery (20) is securely fastened.
The battery (20) is the device key on some models.
• Make sure that the controls for the device drive, if
any, are out of operation.
• Models with electric starter (17a). Press the engine
brake lever (3) against the handle. Operate the
electric starter (17a). The engine will start.
Start the engine (Fig. 14)
• Make sure that the device is connected properly to
the spark plug (10).
• Stand behind the mower. One hand pushes the en-
gine brake lever (3) to the handle (1), the other hand
should be on the pull starter (17).
• Start the engine with the pull starter (17). To do this
pull the handle approx. 10 – 15 cm (until you feel a re-
sistance) and then start the engine with a sharp pull.
If the engine does not start, pull on the handle
again.
