3.1 Attach Arm Assembly to Wall Plate
STEP 3 Hang TV onto Wall Plate
1
2
05
11
05
3.2 Attach TV to Arm Assembly
HEAVY! You may need assistance with this step.
HEAVY! You may need assistance with this step.
11
11
CAUTION: Avoid potential
injuries or property damage!
Locking screw
13
and washer
14
MUST be installed to secure
the TV mount and the arm assembly.
13
14
15
1
NOTE: For WOOD STUD APPLICATIONS, the arm assembly
11
can be
slid anywhere along wall plate
08
for optimal positioning of your TV.
08
2
11
08
CAUTION: Avoid potential personal injury or property damage!
For CONCRETE
APPLICATIONS:
The arm assembly
11
MUST remain centered
in wall plate
08
.
08
11
3
4
65
S
12
12
15
15
